A810314000009 Slide block assembly
10419481 Boom assembly RSC45.10
10419481 Boom assembly RSC45.10
10419481 Boom assembly RSC45.10
10201648 Lifting cylinder RSC45.10.12B
10424848 Expansion Oil Cylinder Assy
10202942 Damping Oil Cylinder
A810103070033 Traveling system RSC45.12
10945117 Working oil tank assembly RSC45C.13
10945119 Fuel tank assembly RSC45C.14
10945119 Fuel tank assembly RSC45C.14
10945119 Fuel tank assembly RSC45C.14
10679877 Movement mechanism of cab RSC45C.15
10084878 Air conditioning system RSC45M.9
A221600000088 Air conditioning assembly KGT4601
10557614 Fire fighting system RSC45C.20
1
1
2
3
4
5
6
7
8
9
10
10
11
11
12
13
14
15
Позиция на иллюстрации
Заводской номер детали
Название детали
1
A820699000681
Slide Block
2
A820101328184
Main part support
3
A820101328185
Cushion
4
A820101331192
Cushion
5
A820101339720
Spacer
6
A210110000233
Bolt
7
A229900007631
Nut M20 Grade 10 Shibilao Hexagon flange
8
A820101328187
Straight Key
9
A210204000220
Screw
10
A210204000337
Screw
11
A210405000001
Washer
12
10180747
End baffle component
13
10182627
End baffle component
14
10971562
Key 1
15
10971566
Key 2
