Каталог запасных частей к технике: SANY RSC45C. A810201055624 Right operation panel assembly RSC45.6.4

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Позиция на иллюстрации Заводской номер детали Название детали
1 B249900001173 Control handle
2 B240500000009 Flash buzzer AD16-22SM/R23
3 B240200000059 Switch, stop, emergency, red, XB2-BS542
4 B241200000484 Key Switch
5 B241200000030 Switch, ignition
6 B241200000612 Vane switch
7 B241200000083 Switch, rocker, 6GM-004-570-067
8 B241200000028 Switch 6FH-004-570-13
9 B249900000091 Limit switch, 8HG-716-734-00
10 B249900000092 Frame, 8HG-716-735-00
11 B241200000185 Protective sleeve, 8-wire socket, 8JA-713-(631-0019)Q/SY1149
12 B240200000081 Contact block, normally-opened, ZB2-BE101C
13 B240200000082 Normally closed contact block ZB2-BE102C
14 B241800000043 Mark Card
15 B241800000009 Mark Card
16 B241800000023 Mark Card
17 B241800000001 Mark card 9XT-713-630-021
18 A241000000040 Socket, blade, DJ623-A6.3B
19 B241200000594 12-pin plug adaptor HDT06-12SA-CE05Q/SY1149
20 B241200000588 Secondary pole lock 12-line (socket)HW12S-P012
21 A242000000007 Terminal UT 1-3
22 A241000000105 Socket DJ621-9.5x1.2D
23 B241200000591 Protective sleeve assy. for 3-wire plug
24 B241200000585 Secondary pole lock 3-line (socket
25 B241200000590 Jacket, socket, two-wire
26 B241200000584 lock, secondary pole, 2-line
27 B229900001093 Receptacle
28 A241900000055 Wire QVR-0.75JB8139 Black
29 A239900000563 Nylon corrugated tube 1/2"
30 A241400000018 Thermal shrinkage tube
31 A241400000180 Thermal shrinkage tube
32 B290000000355 Cap 9HB-713-629-00
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
