Каталог запасных частей к технике: SANY RSC45C. 10945117 Working oil tank assembly RSC45C.13

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Позиция на иллюстрации Заводской номер детали Название детали
1 10945116 Working oil tank body RSC45C.13.1
2 A222100000264 Air cleaner EF7-100
3 A210111000089 Bolt
4 A210404000005 Washer
5 A210401000017 Washer
6 A820101312819 Front cover on left RSC45.13-1
7 10187941 Rear bracket of oil tank RSC45.14.9
8 A210491000118 Washer 16GB1230
9 A210401000004 Washer
10 A210111000112 Bolt
11 10835451 Cover plate of oil pipe RSC45M.4.4
12 10835443 Oil return cover plate RSC45M.4.3
13 A210111000018 Bolt
14 A210401000001 Washer
15 10121195 Manhole cover plate assembly SDCY90K7.3.2
16 A210609000295 O-ring 387x7GB3452.1
17 A210434000015 Washer
18 21051814 Screw plug M30x2QC385
19 A210609000082 O-ring
20 10774636 Cover plate of oil cleaner hole RSC45M.4-3
21 10187917 Front bracket of oil tank RSC45.14.8
22 A210111000040 Bolt
23 A210404000004 Washer, 12 GB96.1
24 A210401000002 Washer
25 A210307000001 Nut
26 10043048 Pedal (2) RSC45M.4-2
27 10043025 Pedal (1) RSC45M.4-1
28 A210405000011 Washer
29 10465351 Pedal bracket RSC45M.5.2
30 60030671 Liquid level and temperature gauge YWZ-400T-B nylon
31 B210780000112 Nut
32 B210780000091 Plug
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
