Каталог запасных частей к технике: SANY RSC45C. 10468244 Moveable counterweight system RSC45M.3.7

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
11
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Позиция на иллюстрации Заводской номер детали Название детали
11 A210204000045 Screw, M16x90 GB70.1
12 A210401000004 Washer
13 A210405000003 Washer
14 A810401071013 Short pressure plate welding
15 A820103010620 Upper sliding rail
16 A210204000160 Screw
17 10042924 Moveable counterweight
18 A210204000095 Screw
19 A210401000008 Washer
20 A210405000009 Washer
21 A820401000144 Lower guide track (1)
22 10239551 Adjusting spacer of long clamp plate
23 A810401071012 Long clamp plate welding
24 10421313 Counterweight supporting board (1)
25 A210307000040 Nut
26 A210111000291 Bolt
27 10421311 Counterweight supporting board (2)
28 A210204000078 Screw
29 A210307000030 Nut
30 A210204000080 Screw
31 A820401000145 Lower guide track (2)
32 10240838 Adjusting spacer of short clamp plate
33 10470206 Limit Stop
34 A210204000273 Screw, M16x35 GB70.1-grade 12.9
35 A210204000338 Screw
36 A820101315967 Stopper
37 A820102010500 Card
38 A820102010501 Adjusting shim
39 A210401000017 Washer
40 A210204000146 Screw, M8x16 GB70.1
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
