Каталог запасных частей к технике: SANY RSC45C. 10419481 Boom assembly RSC45.10
1
2
3
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 10201903 | Lifting boom RSC45.10C.1 | |
| 2 | A820101032859 | Upper baffle RSC45.10-1 | |
| 3 | A820101032860 | Lower baffle RSC45.10-3 | |
| 4 | A210110000285 | Bolt M12x60GB5782 | |
| 5 | A210401000002 | Washer | |
| 6 | A210307000001 | Nut | |
| 7 | A820301017302 | Oil cup bolt (2)RSC45.10-26 | |
| 8 | A820499000044 | Side sliding block RSC45.10-14 | |
| 9 | A820201000711 | Retainer RSC45.10-5 | |
| 10 | A210401000004 | Washer | |
| 11 | A210204000198 | Screw | |
| 12 | A820101312402 | Side slide block spacer RSC45.10-15 | |
| 13 | A229900007632 | Nut M24 10 Shibilao hexagonal flange | |
| 14 | A820301017301 | Oil cup bolt (1)RSC45.10-25 | |
| 15 | A210804000001 | Nipple, grease | |
| 16 | 10201648 | Lifting cylinder RSC45.10.12B | |
| 17 | A210416000022 | Retainer ring 68GB893.1 | |
| 18 | 10201907 | Shaft assembly of lifting cylinder RSC45.10C.6 | |
| 19 | A210491000122 | Washer, 24 GB1230 | |
| 20 | A210401000008 | Washer | |
| 21 | A210111000292 | Bolt | |
| 22 | 10859971 | Rolling bearing | |
| 23 | 10859963 | Slide bearing RSC45.10-32 | |
| 24 | 10201926 | Rear shaft assembly RSC45.10C.9 | |
| 25 | A210111000112 | Bolt | |
| 26 | 11272687 | "Component, slide, lower, RSC45.10.15A" | |
| 27 | 10089451 | Supporting frame RSC45.10.21 | |
| 28 | A820101341776 | Rainproof cover of sensor RSC45.10-24 | |
| 29 | A210210000010 | SCREW | |
| 30 | A210401000016 | Washer | |
| 31 | A820101337402 | Mounting plate of displacement sensor RSC45.10-23 | |
| 32 | A210111000125 | Bolt | |
| 33 | A210405000011 | Washer | |
| 34 | A210401000001 | Washer | |
| 35 | 11044952 | Eccentric sleeve RSC45.10-31 | |
| 36 | A820101312406 | Rear baffle RSC45.10-17 | |
| 37 | A210111000227 | Bolt, M16x30 GB5783 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
