Каталог запасных частей к технике: SANY RSC45C. 10117173 Nameplate assembly RSC45M.7

Тип техники

Марка

Модель

Схема

1

2

3

3

3

3

3

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

Позиция на иллюстрации	Заводской номер детали		Название детали
1	10061340		Safety load nameplate RSC45(B).7-29
2	10997589		Caution board of "Moving without People" RSC45C.7-40
3	10026260		Hoisting point Indicator RSC45(B).7-5
4	A210506000018		Rivet 3x8GB867
5	10026017		Caution board of "No Climbing" RSC45(B).7-2
6	10991382		Anti-clamping caution board RSC45C.7-8
7	10027027		Tyre pressure nameplate RSC45(B).7-26
8	10450544		Oil level indicator (H) RSC45M.7-7
9	10450545		Oil level indicator (L) RSC45M.7-8
10	10580062		Lubrication points nameplate RSC45M.7-1
11	10026753		Hydraulic pressure nameplate RSC45(B).7-15
12	11043479		Maintaince nameplate RSC45M.7-43
13	10580063		Hydraulic oil tank nameplate RSC45M.7-2
14	10706191		Caution board of "No jumpping" RSC45M.7-22
15	10706190		Caution board of "No stopover" RSC45M.7-21
16	10580064		Caution board of spreader RSC45M.7-3
17	10706180		Caution board of "Beware of hanging pieces!!" RSC45M.7-11
