10084878 Air conditioning system RSC45M.9
A221600000088 Air conditioning assembly KGT4601
10557614 Fire fighting system RSC45C.20
1
2
3
4
4
5
6
6
7
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Позиция на иллюстрации
Заводской номер детали
Название детали
1
A221600000088
Air conditioning assembly KGT4601
2
A210204000181
Screw
3
A210401000001
Washer
4
A210405000011
Washer
5
A810505030009
Filter element protective cover RSC45.16.1
6
A210405000005
Washer
7
A210401000015
Washer
8
A210210000006
Screw, M5x10 GB818
9
11435256
Defrosting air duct SRSC45C.16A.1
10
11437241
Main air pipe SRSC45C.16A.2A
11
A210210000002
Screw
12
A210855000011
Circle
13
A230103000012
Vapor rubber hose 16(5.5m)
14
A820599000956
Joint RSC45.16-1
15
A820205002290
Joint RSC45.16-3
16
A210855000007
Circle
17
11448954
Air compressor support RSC45C.16.2
18
A210111000090
Bolt
19
A210401000017
Washer
20
A210405000007
Washer
21
A210111000027
Bolt
22
A210307000017
Nut
23
A210855000012
Hoop, throat
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
