11156030 Air conditioning system SRSC45F.16
11156030 Air conditioning system SRSC45F.16
60051847 Air conditioning assembly KGT4610 Container Reach Stacker F
60051847 Air conditioning assembly KGT4610 Container Reach Stacker F
60040111 Air conditioning assembly KGT4607 for Empty Container Handler F
10557614 Fire fighting system RSC45C.20
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Позиция на иллюстрации
Заводской номер детали
Название детали
4
A210855000024
Throat collar 40-60JB8870
5
A210855000012
Hoop, throat
6
A210111000018
Bolt
7
A210401000001
Washer
8
A210405000011
Washer
9
A230103000012
Vapor rubber hose 16(5.5m)
10
A210855000003
Hoop
11
A820599000956
Joint RSC45.16-1
12
A210855000008
Throat collar 22-32JB8870
13
A820205002290
Joint RSC45.16-3
14
A210401000017
Washer
15
A210405000007
Washer
16
A210111000090
Bolt
17
A820403000915
Air compressor support RSC45.16-4
18
A210111000027
Bolt
19
A210307000017
Nut
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
