Каталог запасных частей к технике: SANY RSC45C. 10679877 Movement mechanism of cab RSC45C.15

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
5
6
6
7
8
9
10
11
12
12
12
12
13
13
13
13
14
14
14
14
15
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
Позиция на иллюстрации Заводской номер детали Название детали
1 11244986 Oil cylinder for moving right RSC45C.15.3A
2 10856971 Roller wheel 2 RSC45C.15-1A
3 A210414000107 Retainer ring 14GB894.1
4 A210111000026 Bolt
5 A210405000011 Washer
6 A210401000001 Washer
7 A210307000017 Nut
8 10976003 Guide wheel component RSC45C.15.12
9 10679843 Pallet RSC45C.15.2
10 10940028 Sound insulation board assembly RSC45M.2A.10
11 A810402990076 Front wheel installation seat RSC45M.15.3
12 A210111000203 Bolt
13 A210401000002 Washer
14 A210405000001 Washer
15 A210307000031 Nut
16 A222000000026 Vibration damper Y20-26-00
17 A210111000018 Bolt
18 A210110000281 Bolt
19 A210405000003 Washer
20 A210401000004 Washer
21 A810402990075 Rear wheel installation seat RSC45.15.1
22 A820101314487 Shaft end baffle RSC45.15-17
23 A210401000016 Washer
24 A210111000079 Bolt
25 A820301014294 Shaft (3)RSC45.15-18
26 10649834 Roller wheel RSC45.15-9A
27 10218356 Anti-overturn plate RSC45M.15C-1
28 A210204000162 Screw
29 10866236 Right connecting component RSC45C.15.7
30 11244869 Connecting component RSC45C.15.1B
31 10676118 Right baffle RSC45C.15-3
32 10676117 Bolt RSC45C.15-2
33 10120851 Front Ear holder assembly RSC45M.15.7
34 11303555 Cover plate SRSC45F_15A-7
35 A210210000024 Screw
36 A210405000006 Washer
37 10676121 "Component, connecting rod, left"
38 10866238 "Plate, left"
39 11403773 Right moveable oil cylinder
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
