10201648 Lifting cylinder RSC45.10.12B
10424848 Expansion Oil Cylinder Assy
10202942 Damping Oil Cylinder
A810103070033 Traveling system RSC45.12
10945117 Working oil tank assembly RSC45C.13
10945119 Fuel tank assembly RSC45C.14
10945119 Fuel tank assembly RSC45C.14
10945119 Fuel tank assembly RSC45C.14
10679877 Movement mechanism of cab RSC45C.15
11156030 Air conditioning system SRSC45F.16
11156030 Air conditioning system SRSC45F.16
60051847 Air conditioning assembly KGT4610 Container Reach Stacker F
60051847 Air conditioning assembly KGT4610 Container Reach Stacker F
60040111 Air conditioning assembly KGT4607 for Empty Container Handler F
10557614 Fire fighting system RSC45C.20
1
2
3
4
5
6
7
8
8
9
9
10
11
12
12
13
14
15
16
17
18
19
19
19
19
20
21
Позиция на иллюстрации
Заводской номер детали
Название детали
1
10201646
Ear RSC45.10.12B-1
2
10032541
Nut RSC45.10.12A-2
3
10032542
Nut RSC45.10.12A-3
4
10032544
Guide sleeve RSC45.10.12A-4
5
10032545
Piston RSC45.10.12A-5
6
10032549
Piston rod component RSC45.10.12A.1
7
10201638
Cylinder component RSC45.10.12B.2
8
B230101000295
B8 Seal ring 205x230x20 Parker
9
B230101001567
CRMD Seal ring 230x205x25.4 Skf
10
B230101000903
Guide ring GP7502300C380-225x230x25 Busaksh
11
A210208000007
Screw, M10x20 GB79
12
A210609000186
O-ring 218x7GB3452.1 fluorin rubber
13
10194909
Retainer ring RSC45.10.12A-6
14
B230101001964
Ring, guide, GR75A1800C380-180x185x25
15
A880806030018
CRGS Seal ring 180x195.1x6.3 AD1 Skf
16
B230101001441
B3 Seal ring 180x205x18.2 Parker
17
B230101000513
Dust shield ring A1J010P5008 Parker
18
A210416000050
Retainer ring 210GB893.1
19
A210804000002
Cup, oil
20
B210399000003
Screw plug, VSTI10x1EDA3C
21
60025306
Joint bearing GEH120TXA-2LS
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
