Каталог запасных частей к технике: SANY QY50CS93. 10208511 Cooling system

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
13
14
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
36
37
38
39
40
41
42
43
44
45
Позиция на иллюстрации Заводской номер детали Название детали
1 A810102099102 Rod assy, cooler, oil
2 10009177 Clamp strip assy, compensating tank
3 10345466 Pipe assy, steel, inlet, cooling water, engine
4 A210401000017 Washer
5 A210405000007 Washer
6 A210401000001 Washer
7 A210405000011 Washer
8 A210405000003 Washer
9 60022386 Valve, ball
10 A210855000003 Hoop
11 A220201000051 Radiator
12 A229900003312 Hoop, ring, hose
13 10089491 Joint, heater
14 10107345 Hose, rubber, degassing
15 10108187 Water pipe, warm wind, I
16 10108200 Water pipe, warm wind, II
17 11049791 Water pipe, warm wind, III
18 A820101329381 Strap
19 A820606030687 Pipe, cooling water adding, engine
20 A820606010821 Mat, rubber, cooler, oil
21 A820101329617 Disk, steel plate
22 A820606020404 Hose, outlet, cooling water, cooler, oil
23 A210319000001 Nut
24 A210111000197 Bolt
25 A210111000120 Bolt
26 A210319000012 Nut
27 A210110000048 Bolt
28 A210307000012 Nut
29 A210319000004 Nut
30 A210111000090 Bolt
31 A210111000091 Bolt
32 A210111000092 Bolt
33 A229900002964 Hoop, ring, hose
34 A229900002966 Strap, hose
35 A229900001347 Hoop - Hose
36 A229900009206 Cover, fan
37 10177385 Hose, bend, rubber
38 10113558 Mat, rubber, compensating tank
39 10345459 Pipe, steel, outlet, cooling water, engine
40 10208507 Hose, rubber, outlet, cooling water, rubber, straight
41 10345464 Joint shaft, fan
42 10208508 Hose, inlet, cooling water, straight
43 10583244 Bracket, pipe, steel, water inlet, engine
44 A229900005225 Expansion water tank assembly
45 A229900007324 Fan
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
