Каталог запасных частей к технике: RM-Terex TL-310. Hydraulic Installation - Circulation >Tl03100122
1
2
3
4
5
6
7
8
8
9
10
11
12
13
13
14
14
14
14
15
16
17
18
19
20
21
22
22
23
23
24
24
25
26
27
28
29
30
31
32
32
33
34
34
35
36
37
38
39
41
42
43
44
45
46
47
48
48
49
50
51
52
53
54
56
57
57
58
59
60
61
62
64
64
65
66
67
68
68
69
69
71
72
72
73
74
75
76
77
78
79
81
82
83
84
84
85
86
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4138470260 | Hose | |
| 2 | 5000587724 | Flange, Half | |
| 3 | 1971958332 | O-Ring | |
| 4 | 1045707829 | Screw | |
| 5 | 4120100156 | Hose | |
| 6 | 4120060156 | Hose | |
| 7 | 1924060156 | Fitting Ewsd | |
| 8 | 1915060266 | Fitting | |
| 9 | 0458017025 | Suction Flange Cpl. | |
| 10 | 1971956532 | O-Ring | |
| 11 | 1045707590 | Bolt | |
| 12 | 5000210410 | Hose Clip | |
| 13 | 5210657274 | Hose | |
| 14 | 5660200120 | Hose Clip | |
| 15 | 0458017020 | Suction Pipe | |
| 16 | 5050650844 | Pressure Switch | |
| 17 | 1939000415 | Fitting | |
| 18 | 1971956315 | Seal | |
| 19 | 1045707690 | Bolt | |
| 20 | 5066253810 | Minimess-Coupling | |
| 21 | 4475600734 | Hose | |
| 22 | 5368654770 | Bracket | |
| 23 | 5660200050 | Cover | |
| 24 | 1007707025 | Bolt | |
| 25 | 1939060201 | Straight Fitting | |
| 26 | 4256611317 | Hose | |
| 27 | 1939060209 | Fitting | |
| 28 | 4116190376 | Hose | |
| 29 | 1915000216 | Screwed Socket | |
| 30 | 4132225217 | Hose | |
| 31 | 5660199644 | Hose Clip | |
| 32 | 5660200160 | Cover Plate | |
| 33 | 1915060670 | Screw-In Socket | |
| 34 | 4120170156 | Hose | |
| 35 | 5660199803 | Hose Clip | |
| 36 | 5660200140 | Cover | |
| 37 | 1007707214 | Hexagon Bolt | |
| 38 | 5066253605 | Minimess Coupling | |
| 39 | 5100620049 | Gear Pump | |
| 41 | 5050588910 | Flange Connection | |
| 42 | 1970956720 | O-Ring | |
| 43 | 1045707318 | Bolt | |
| 44 | 4125150189 | Hose | |
| 45 | 1938060303 | Fitting | |
| 46 | 1919060354 | Fitting Elsd | |
| 47 | 5066234220 | Measuring Connecti | |
| 48 | 5660199787 | Hose Clip | |
| 49 | 4262450375 | Hose Pipe | |
| 50 | 1915060469 | Fitting | |
| 51 | 5260310343 | Manifold | |
| 52 | 1912060361 | Plug | |
| 53 | 1911060161 | Union Nut | |
| 54 | 5660199646 | Hose Clip | |
| 56 | 1970956120 | O Ring | |
| 57 | 1321707014 | Spring Washer | |
| 58 | 1915060272 | Straight Fitting G | |
| 59 | 5660199938 | Hose Clamp | |
| 60 | 5660200060 | Cover Plate | |
| 61 | 1007707831 | Bolt | |
| 62 | 5000210400 | Hose Clip | |
| 64 | 5660200130 | Cover | |
| 65 | 1007707014 | Screw | |
| 66 | 1045707313 | Pan Head Screw | |
| 67 | 1045707813 | Pan Head Screw | |
| 68 | 1007707714 | Screw | |
| 69 | 1007707814 | Bolt | |
| 71 | 1915060480 | Fitting | |
| 72 | 5260310379 | Angled Pipe | |
| 73 | 1924060159 | Fitting | |
| 74 | 1943000101 | Fitting | |
| 75 | 1915060268 | Fitting | |
| 76 | 1636815354 | Seal Ring | |
| 77 | 1924060151 | Fitting | |
| 78 | 1007707125 | Bolt | |
| 79 | 1007707519 | Hexagon Bolt | |
| 81 | 5653093560 | Binder | |
| 82 | 5350650280 | Cable Binder | |
| 83 | 1045707124 | Screw | |
| 84 | 1343707059 | Washer | |
| 85 | 1007707425 | Screw | |
| 86 | 1212251013 | Nut |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
