Каталог запасных частей к технике: RM-Terex TL-310. Electric Installation - Console - Switch
4
5
6
7
8
10
11
11
12
12
13
14
14
14
14
14
14
14
14
15
16
16
16
17
18
19
20
21
22
23
24
25
26
27
47
48
49
50
57
58
59
63
69
71
72
73
79
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4 | 5050655525 | Ignition Switch | |
| 5 | 5050650256 | Ign Key | |
| 6 | 5050650261 | Plug | |
| 7 | 5050650262 | Plug | |
| 8 | 5050650225 | Housing | |
| 10 | 5050650222 | Bulb | |
| 11 | 5050650231 | Housing | |
| 12 | 5350246805 | Flat Plug | |
| 13 | 5050651556 | Hazard Switch | |
| 14 | 5050651552 | Rocker Switch | |
| 15 | 5578651581 | Tank Cap | |
| 16 | 5050651590 | Lever Key | |
| 17 | 5358650236 | Symbol | |
| 18 | 5358650240 | Symbol | |
| 19 | 5358650296 | Symbol | |
| 20 | 5358650237 | Symbol Occ. Light | |
| 21 | 5358650337 | Symbol | |
| 22 | 5358650288 | Symbol | |
| 23 | 5358650384 | Symbol | |
| 24 | 5358650391 | Symbol | |
| 25 | 5358650245 | Symbol | |
| 26 | 5358650392 | Symbol | |
| 27 | 5358650355 | Symbol | |
| 47 | 0455040065 | Wire Harness | |
| 48 | 5350249542 | Plug | |
| 49 | 5350247311 | Flat Plug | |
| 50 | 5350249541 | Plug | |
| 57 | 5050651286 | Control Light | |
| 58 | 5358650335 | Insert Without Sy. | |
| 59 | 5358650334 | Insert Without Sy. | |
| 63 | 5358650252 | Insert Without Sy. | |
| 69 | 5050651583 | Rocker Switch | |
| 71 | 5050650316 | Lamp With Socket | |
| 72 | 5050650230 | Cover | |
| 73 | 5358650439 | Symbol | |
| 79 | 5358650425 | Symbol |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
