Каталог запасных частей к технике: RM-Terex TL-310. Electric Installation - Console
1
2
3
28
29
31
32
33
34
34
34
34
34
34
34
34
35
36
37
41
43
43
44
45
51
51
51
51
51
52
52
53
53
54
55
56
60
61
62
62
62
64
65
65
65
65
65
67
67
67
68
70
74
75
76
76
80
81
82
85
86
90
91
95
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6456040340 | Wire Harness | |
| 2 | 6451045100 | Control Box | |
| 3 | 5322000008 | Add-On Modul | |
| 28 | 5350249754 | Socket Insert | |
| 29 | 5350249755 | Socket Insert | |
| 31 | 5350249762 | Socket Insert | |
| 32 | 5350249753 | Socket Insert | |
| 33 | 5350249751 | Socket Insert | |
| 34 | 5350249552 | Element | |
| 35 | 5350249694 | Flat Plug | |
| 36 | 5350249693 | Flat Plug | |
| 37 | 5350249692 | Flat Plug | |
| 41 | 5110661577 | Full Floating Axle | |
| 43 | 5050650420 | Plate | |
| 44 | 5350246610 | Cable Connector | |
| 45 | 5350249630 | Connector | |
| 51 | 5350246805 | Flat Plug | |
| 52 | 1045707909 | Screw | |
| 53 | 1290707012 | Washer | |
| 54 | 1290707020 | Washer 10.5 | |
| 55 | 1330620020 | Plate | |
| 56 | 1212251013 | Nut | |
| 60 | 0455046090 | Bracket | |
| 61 | 1045707213 | Pan Head Screw | |
| 62 | 1343707055 | Washer | |
| 64 | 5350249688 | Housing | |
| 65 | 5350249695 | Flat Plug | |
| 67 | 5350249505 | Housing | |
| 68 | 5110661578 | Full Floating Axle | |
| 70 | 5350249685 | Socket | |
| 74 | 5653093560 | Binder | |
| 75 | 5350650280 | Cable Binder | |
| 76 | 1008707513 | Hexagon Bolt | |
| 80 | 5350249691 | Flat Plug | |
| 81 | 5050651209 | Housing | |
| 82 | 5050651211 | Housing | |
| 85 | 5350249942 | Plug Housing | |
| 86 | 5350249943 | Flat Plug | |
| 90 | 5350247525 | Voltage Transform | |
| 91 | 5350247530 | Potential Transformer | |
| 95 | 0456318021 | Wire Harness |
