Каталог запасных частей к технике: RM-Terex TC-50. Cover, Engine Hood >Tc00500545 -0534-0544
1
2
3
3
3
3
3
4
4
4
4
4
4
4
4
5
5
6
7
7
7
7
8
8
8
8
8
8
8
9
9
9
9
9
9
9
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
23
24
25
26
27
27
28
28
29
30
30
31
32
33
34
37
38
40
40
40
40
41
41
41
42
42
42
43
44
45
46
47
49
50
51
52
53
54
55
56
57
57
57
57
58
59
60
61
63
64
65
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 0219528105 | Cover | |
| 2 | 6216028148 | Hood Prop | |
| 3 | 1307707018 | Washer | |
| 4 | 1210707011 | Nut | |
| 5 | 1212251011 | Nut | |
| 6 | 1008707818 | Hexagon Bolt | |
| 7 | 0216028117 | Threaded Plate | |
| 8 | 1008707318 | Hexagon Bolt | |
| 9 | 1343707057 | Washer | |
| 10 | 5354604476 | Clip | |
| 11 | 6217528040 | Angle | |
| 12 | 0219528006 | Hood | |
| 13 | 1576000630 | Handle | |
| 14 | 1133907105 | Set Screw | |
| 15 | 1343707059 | Washer | |
| 16 | 1210707013 | Nut | |
| 17 | 1576000628 | Handle | |
| 18 | 1978000028 | Rubber Washer | |
| 19 | 6219528023 | Bracket | |
| 20 | 5314639355 | Rubber Pad | |
| 21 | 6188814225 | Washer | |
| 22 | 6219528140 | Partition Wall | |
| 23 | 1008707423 | Screw | |
| 24 | 6216028147 | Angle | |
| 25 | 5101290955 | Rubber Stop | |
| 26 | 1008707213 | Hexagon Bolt | |
| 27 | 1343707055 | Washer | |
| 28 | 1212251009 | Hexagon Nut | |
| 29 | 1210707009 | Nut | |
| 30 | 6216028130 | Hinge | |
| 31 | 5354604474 | Lock | |
| 32 | 6219528175 | Valve Cap | |
| 33 | 1157707912 | Wing Bolt | |
| 34 | 1343707055 | Washer | |
| 37 | 1045707120 | Pan Head Screw | |
| 38 | 1290707018 | Washer | |
| 40 | 1069707909 | Bolt | |
| 41 | 1290707012 | Washer | |
| 42 | 1212251007 | Nut | |
| 43 | 6219623005 | Cover | |
| 44 | 6219528021 | Shop | |
| 45 | 1008707618 | Hexagon Bolt | |
| 46 | 6219528163 | Bracket | |
| 47 | 6219528051 | Angle | |
| 49 | 6219624003 | Sheet metal side panel | |
| 50 | 6219624004 | Sheet metal side panel | |
| 51 | 5354620113 | Hinge | |
| 52 | 1008707513 | Hexagon Bolt | |
| 53 | 1290707014 | Washer | |
| 54 | 5354640125 | Neoprene Strip | |
| 55 | 0219516010 | Exhaust Hood | |
| 56 | 5529050040 | Lining Set | |
| 57 | 1307707020 | Washer | |
| 58 | 5388661476 | Rubber Buffer | |
| 59 | 6219528065 | Angle | |
| 60 | 0219528180 | Pin | |
| 61 | 6219528184 | Lasche | |
| 63 | 1008707124 | Hexagon Bolt | |
| 64 | 6216028149 | U Plate | |
| 65 | 6219528066 | U Plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
