Каталог запасных частей к технике: RM-Terex CD TFC45LX hc SIDER. COOLER HYD. CIRCUIT
1
2
3
4
5
5
6
6
7
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | R6226253 | SUPPORT | |
| 2 | M2733009 | SCREW | |
| 3 | E0034711 | WASHER | |
| 4 | P0445362 | WASHER | |
| 5 | D2733070 | SCREW | |
| 6 | C0034709 | WASHER | |
| 7 | B0235015 | WASHER | |
| 8 | N2034569 | NUT | |
| 9 | U6742238 | HOSE | |
| 10 | H6742250 | HOSE | |
| 11 | A6842270 | HOSE | |
| 12 | G6642268 | HOSE | |
| 13 | K6242232 | HOSE | |
| 14 | J6742251 | HOSE | |
| 15 | Q7731970 | HOSE | |
| 16 | K7431907 | HOSE | |
| 17 | E6842228 | HOSE | |
| 18 | A6642239 | HOSE | |
| 19 | J6642270 | HOSE | |
| 20 | K6642271 | HOSE | |
| 21 | L6642272 | HOSE | |
| 22 | T9331991 | HOSE | |
| 23 | H7531978 | HOSE | |
| 24 | H7731917 | HOSE | |
| 25 | W1137278 | T PIECE | |
| 26 | S4337540 | CONNECTION | |
| 27 | L2837589 | UNION | |
| 28 | U7041813 | DETECTOR | |
| 29 | P8552264 | ELECTRIC BEAM | |
| 30 | N6141173 | RELAY | |
| 31 | H0032621 | SCREW | |
| 32 | A0034707 | WASHER | |
| 33 | T3041468 | WASHER | |
| 34 | P2034570 | NUT | |
| 35 | D0136922 | COLLAR |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
