Каталог запасных частей к технике: RM-Terex CD TFC45LX hc SIDER. CONVERTER HOUSING
1
2
3
3
3
4
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
15
16
17
18
18
18
19
19
20
20
20
21
22
23
24
25
26
27
27
28
29
30
31
32
33
34
35
36
39
39
40
40
40
41
41
41
42
42
42
43
43
43
44
45
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | X8838944 | GEAR BOX BODY | |
| 2 | Z8838945 | GEAR BOX BODY | |
| 3 | P6537487 | PLUG | |
| 4 | W6537494 | PLUG | |
| 5 | P6330441 | O-RING | |
| 6 | Q6850173 | GEAR BOX PIPE | |
| 7 | R6850174 | GEAR BOX PIPE | |
| 8 | S6850175 | GEAR BOX PIPE | |
| 9 | D6336963 | PLATE | |
| 10 | G2330458 | O-RING SEAL | |
| 11 | C0633031 | SCREW | |
| 12 | T3045493 | WASHER | |
| 13 | T6850176 | GEAR BOX PIPE | |
| 14 | G0329412 | BUSHING | |
| 15 | R0229486 | BUSHING | |
| 16 | S0229487 | BUSHING | |
| 17 | T0229488 | BUSHING | |
| 18 | M0545410 | WASHER | |
| 19 | C0633031 | SCREW | |
| 20 | T3045493 | WASHER | |
| 21 | X2437446 | PLUG | |
| 22 | R6537489 | PLUG | |
| 23 | K2330461 | O-RING SEAL | |
| 24 | S0527314 | SAFETY-PIN | |
| 25 | J6034012 | SCREW | |
| 26 | C0234027 | SCREW | |
| 27 | L0334706 | WASHER | |
| 28 | E5351092 | JUNTA | |
| 29 | A7437579 | UNION | |
| 30 | B1750531 | BREATHER | |
| 31 | H0437467 | PLUG | |
| 32 | T6941624 | SENSOR | |
| 33 | R8452216 | WIRE HARNESS | |
| 34 | T6741662 | SENSOR | |
| 35 | F6330433 | O-RING SEAL | |
| 36 | R6741660 | SENSOR | |
| 39 | S6537490 | PLUG | |
| 40 | F6251060 | PLATE | |
| 41 | G6330434 | SEAL | |
| 42 | K6034013 | SCREW | |
| 43 | S0234731 | WASHER | |
| 44 | R6537489 | PLUG | |
| 45 | K2330461 | O-RING SEAL |
