Каталог запасных частей к технике: PENGPU PengPu PD-320. ROLL OVER PROTECTIVE STRUCTURE BRACKET PD320Y-2
1
2
2
3
3
3
3
4
5
6
7
8
9
10
10
10
10
11
12
13
13
14
14
15
15
16
16
16
16
17
17
18
18
18
19
19
19
19
19
20
20
21
21
22
22
23
24
25
26
27
28
28
29
29
32
33
33
34
34
35
36
38
39
40
40
40
41
42
43
44
44
45
46
47
48
49
50
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | T14A.978.1 | BRACKET | |
| 2 | JB/ZQ3730 | BOLT | |
| 3 | JB/ZQ3756 | WASHER | |
| 4 | JB/ZQ3730 | BOLT | |
| 5 | T14A.978.2 | PLATE, L.H. | |
| 6 | T14A.978.3 | PLATE, R.H. | |
| 7 | T14A.978.4 | BRACKET | |
| 8 | T14A.978.5 | BRACKET | |
| 9 | GB5782 | BOLT | |
| 10 | JB/ZQ3756 | WASHER | |
| 11 | GB5787 | BOLT | |
| 12 | T14.978-7 | BOLT | |
| 13 | JB/ZQ3756 | WASHER | |
| 14 | GB6170 | NUT | |
| 15 | T21A.978-3 | PLATE | |
| 16 | T21A.978-2 | RUBBER | |
| 17 | T21A.978-1 | BLOCK | |
| 18 | GB5783 | BOLT | |
| 19 | GB93 | WASHER | |
| 20 | T14.978-9 | VOLLAR | |
| 21 | T14.978-1 | BOLT | |
| 22 | GB93 | WASHER | |
| 23 | T14A.978-1 | WASHER | |
| 24 | T14A.978-2 | WASHER | |
| 25 | GB5783 | BOLT | |
| 26 | GB93 | WASHER | |
| 27 | T14A.978-3[1] | COVER | |
| 28 | GB5783 | BOLT | |
| 29 | GB97.1 | WASHER | |
| 32 | T14A.978-5 | COVER | |
| 33 | T14.978-3 | HANDLE | |
| 34 | T14A.978.6 | BRACKET | |
| 35 | T14B.978.1 | BRACKET | |
| 36 | T14.978-2 | WASHER | |
| 38 | T14A.978-6 | BRACKET | |
| 39 | GB5783 | BOLT | |
| 40 | GB97.1 | WASHER | |
| 41 | GB6170 | NUT | |
| 42 | T14A.978-7 | BLOCK | |
| 43 | T14B.978.2 | BRACKET | |
| 44 | GB5783 | BOLT | |
| 45 | T14A.978.8 | BELT | |
| 46 | GB5783 | BOLT | |
| 47 | GB97.1 | WASHER | |
| 48 | GB93 | WASHER | |
| 49 | GB6170 | NUT | |
| 50 | T14B.978.3 | BRACKET |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
