Каталог запасных частей к технике: PENGPU PengPu PD-320. FENDER PD320Y-2 1/2
1
2
3
3
4
4
5
5
5
5
6
7
8
8
9
9
10
10
10
10
11
12
13
13
14
14
15
15
15
15
16
17
18
18
18
19
19
19
20
21
21
21
21
21
21
22
22
23
23
24
25
25
25
25
25
26
26
26
26
27
28
29
30
31
32
33
34
34
35
35
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | T14A.54.15[1] | FENDER, L.H. | |
| 2 | T14B.54.3 | FENDER, R.H | |
| 3 | GB5783 | BOLT | |
| 4 | GB5783 | BOLT | |
| 5 | GB93 | WASHER | |
| 6 | T14A.54.3 | BRACKET | |
| 7 | 54-55 | BRACKET | |
| 8 | GB5783 | BOLT | |
| 9 | GB5782 | BOLT | |
| 10 | GB93 | WASHER | |
| 11 | 54-54 | BRACKET, L.H | |
| 12 | 54-56 | BRACKET, R.H | |
| 13 | GB5783 | BOLT | |
| 14 | GB5782 | BOLT | |
| 15 | GB93 | WASHER | |
| 16 | T14A.54.29 | BRACKET | |
| 17 | T14B.54.10 | BRACKET | |
| 18 | GB5783 | BOLT | |
| 19 | 01643-31645 | WASHER | |
| 20 | T14B.54.6[1] | BRACKET | |
| 21 | 01643-31645 | WASHER | |
| 22 | 01643-32640 | WASHER 24 | |
| 23 | T14A.54-14 | COVER | |
| 24 | G5783 | BOLT M12x35-Zn | |
| 25 | GB97.1 | WASHER | |
| 26 | GB93 | WASHER | |
| 27 | GB5783 | BOLT | |
| 28 | T14.54-11 | PLATE | |
| 29 | GB6170 | NUT | |
| 30 | GB854 | WASHER 12 | |
| 31 | T14A.54.34[1] | FRAME | |
| 32 | T14A.54.17[2] | COVER | |
| 33 | GB5783 | BOLT | |
| 34 | 54-42 | PLATE | |
| 35 | GB5783 | BOLT | |
| 36 | GB93 | WASHER | |
| 37 | GB5783 | BOLT | |
| 38 | 54-50 | HANDLE | |
| 39 | 07049-02430 | PLUG |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
