Каталог запасных частей к технике: PENGPU PengPu PD-320. BRAKE LINKAGE PD320Y-1 PD320Y-2
1
1
1
1
2
2
2
2
3
3
4
4
4
4
5
5
5
5
6
7
8
8
9
9
10
10
11
11
11
11
11
11
12
12
12
12
13
13
14
15
16
17
18
18
18
18
19
20
21
21
22
22
23
24
25
26
27
28
29
30
30
31
32
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | GB91 | PIN | |
| 2 | GB882 | PIN | |
| 3 | T14A.43.4.7 | LEVER | |
| 4 | GB5783 | BOLT | |
| 5 | GB97.2 | WASHER | |
| 6 | T14A.43.4.11 | BRACKET | |
| 7 | 43-42 | LEVER | |
| 8 | GB93 | WASHER | |
| 9 | GB5783 | BOLT | |
| 10 | T19-43.2-3 | SEAT | |
| 11 | 06122-03504 | SEAL | |
| 12 | GB290 | BEARING | |
| 13 | GB1099 | KEY | |
| 14 | GB97.2 | WASHER | |
| 15 | GB5783 | BOLT | |
| 16 | T14A.43.4-1 | SHAFT | |
| 17 | T14A.43.4.4 | SHAFT | |
| 18 | T19-50-6 | JIONT | |
| 19 | T14A.43.4.12 | TUBE | |
| 20 | 08036-10814 | CLAMP | |
| 21 | GB97.1 | WASHER | |
| 22 | GB5783 | BOLT | |
| 23 | 08036-11214 | CLAMP | |
| 24 | GB5783 | BOLT | |
| 25 | GB93 | WASHER | |
| 26 | T19-43.2.27 | SHAFT | |
| 27 | T14A.43.4.17 | SEAT | |
| 28 | T14A.43.4.5 | LEVER | |
| 29 | T19-43.2.26 | SEAT | |
| 30 | GB6171 | NUT | |
| 31 | T14A.43.4.6 | TUBE | |
| 32 | GB1152 | FITTING, GREASE | |
| 33 | 04211-21478 | YOKE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
