Каталог запасных частей к технике: PENGPU PengPu PD-220. FENDER (PD220YS)
1
2
3
3
4
5
6
7
8
8
8
8
8
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
24
25
26
26
27
28
29
30
31
32
33
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
50
51
52
53
54
55
55
56
56
57
57
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | T23.54.9 | FENDER, L.H. | |
| 2 | T23.54.8 | FENDER, R, H | |
| 3 | GB5783 | BOLT | |
| 4 | GB93 | WASHER | |
| 5 | GB97.1 | WASHER | |
| 6 | GB5783 | BOLT | |
| 7 | GB93 | WASHER | |
| 8 | GB97.1 | WASHER | |
| 9 | GB5783 | BOLT | |
| 10 | GB93 | WASHER | |
| 11 | GB5782 | BOLT | |
| 12 | GB93 | WASHER | |
| 13 | GB5782 | BOLT | |
| 14 | GB93 | WASHER | |
| 15 | T21.54-2 | BRACKET | |
| 16 | GB5783 | BOLT | |
| 17 | GB93 | WASHER | |
| 18 | 08037-03620 | TUBE | |
| 19 | T23.54.3 | BRACKET | |
| 20 | T21.54.31 | BRACKET | |
| 21 | GB5782 | BOLT | |
| 22 | GB93 | WASHER | |
| 23 | T21.54-2 | BRACKET | |
| 24 | GB5782 | BOLT | |
| 25 | GB5782 | BOLT | |
| 26 | GB97.1 | WASHER | |
| 27 | GB93 | WASHER | |
| 28 | GB93 | WASHER | |
| 29 | GB5783 | BOLT | |
| 30 | Т21.54-10 | COVER | |
| 31 | GB93 | WASHER | |
| 32 | GB5783 | BOLT | |
| 33 | GB5783 | BOLT | |
| 34 | GB93 | WASHER | |
| 35 | GB97.1 | WASHER | |
| 36 | Т23.54.2 | BRACKET | |
| 37 | GB5783 | BOLT | |
| 38 | GB93 | WASHER | |
| 39 | GB97.1 | WASHER | |
| 40 | Т14А.54.7 | COVER | |
| 41 | 08037-03620 | TUBE | |
| 42 | GB5783 | BOLT | |
| 43 | GB93 | WASHER | |
| 44 | Т23.54.3 | BRACKET | |
| 45 | GB5783 | BOLT | |
| 46 | GB93 | WASHER | |
| 47 | Т21А.54.21 | CASE | |
| 48 | GB5783 | BOLT | |
| 49 | GB93 | WASHER | |
| 50 | GB96 | WASHER | |
| 51 | GB5783 | BOLT | |
| 52 | GB93 | WASHER | |
| 53 | GB5782 | BOLT | |
| 54 | GB97.1 | WASHER | |
| 55 | 54-52 | HANDLE | |
| 56 | GB5782 | BOLT | |
| 57 | GB93 | WASHER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
