Каталог запасных частей к технике: PENGPU PengPu PD-220. FENDER (PD220Y-2)
1
2
3
3
4
5
6
7
8
8
8
8
9
9
10
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
24
24
25
25
26
26
27
28
29
30
31
32
32
33
34
35
36
37
38
39
40
41
42
43
44
45
45
46
47
48
49
50
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | T21A.54.15 | FENDER, L.H. | |
| 2 | T21A.54.13 | FENDER, R.H | |
| 3 | GB5783 | BOLT | |
| 4 | GB93 | WASHER | |
| 5 | GB97.1 | WASHER | |
| 6 | GB5783 | BOLT | |
| 7 | GB93 | WASHER | |
| 8 | GB97.1 | WASHER | |
| 9 | GB5783 | BOLT | |
| 10 | GB93 | WASHER | |
| 11 | GB5782 | BOLT | |
| 12 | GB93 | WASHER | |
| 13 | T21.54-2 | BRACKET | |
| 14 | GB5783 | BOLT | |
| 15 | GB93 | WASHER | |
| 16 | 08037-03620 | TUBE | |
| 17 | T21D.54.7 | BRACKET | |
| 18 | T21.54.31 | BRACKET | |
| 19 | GB93 | WASHER | |
| 20 | T21.54-2 | BRACKET | |
| 21 | GB5782 | BOLT | |
| 22 | GB5782 | BOLT | |
| 23 | GB93 | WASHER | |
| 24 | GB97.1 | WASHER | |
| 25 | GB93 | WASHER | |
| 26 | GB5783 | BOLT | |
| 27 | T21.54-10 | COVER | |
| 28 | GB93 | WASHER | |
| 29 | GB5783 | BOLT | |
| 30 | GB5783 | BOLT | |
| 31 | GB93 | WASHER | |
| 32 | GB97.1 | WASHER | |
| 33 | T21.54.8 | BRACKET | |
| 34 | GB5783 | BOLT | |
| 35 | GB93 | WASHER | |
| 36 | GB97.1 | WASHER | |
| 37 | T14A.54.7 | COVER | |
| 38 | 08037-03620 | TUBE | |
| 39 | GB5783 | BOLT | |
| 40 | GB93 | WASHER | |
| 41 | T21A.54.4 | BRACKET | |
| 42 | T21A.54.21 | CASE | |
| 43 | GB5783 | BOLT | |
| 44 | GB93 | WASHER | |
| 45 | GB96 | WASHER | |
| 46 | GB5783 | BOLT | |
| 47 | GB93 | WASHER | |
| 48 | GB97.1 | WASHER | |
| 49 | T14A.54.37 | FOOTPLATE, R, H | |
| 50 | T14A.54.38 | FOOTPLATE, L, H |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
