87422777
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Позиция на иллюстрации
Заводской номер детали
Название детали
87422777
87422777
Генератор переменного тока
1
87438960
Генератор переменного тока
2
87438963
Корпус
3
87438965
Держатель
4
87438967
Держатель
5
87438969
Регулятор напряжения
6
87438970
Крышка задняя
7
87438971
Втулка
8
87438972
Втулка
9
87438973
Винт
10
87438974
Винт с невыпадающей шайбой
11
87438975
Гайка
12
87438976
Гайка
13
87438977
Крепеж
14
87438978
Шкив
15
87438979
Гайка
16
87438980
Уплотнительное кольцо
17
87438981
Уплотнительное кольцо
18
87438982
Плоская шайба
19
87438983
Винт с невыпадающей шайбой
20
87438984
Пластина
21
87438985
Винт
22
87438986
Шариковый подшипник
23
87438987
Крышка подшипника
24
87438989
Крышка подшипника
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
