1
2
3
4
5
6
7
8
8
8
9
9
9
9
10
11
12
13
14
Позиция на иллюстрации
Заводской номер детали
Название детали
1
17044731
Гайка с фланцем
2
4896952
COVER
3
2852488
STUD, M8X1.25X50
4
4890700
GASKET
5
4898921
PUMP, FUEL INJECTION, ASSY
6
4890088
O-RING
7
4890634
NUT, M18X1.5
8
93156604
Прокладка
9
4893962
COUPLING, QUICK, MALE
10
2852804
HUB, ASSY
11
2852805
O-RING
12
4893389
GEAR, DRIVEN
13
87803136
Винт
14
17095814
Плоская шайба
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
