Каталог запасных частей к технике: MANITOU MT-X1740SLTS3-E3. LIGHTING - SIGNALING
1
2
3
4
5
5
6
6
7
7
8
8
9
9
10
11
12
13
14
15
16
17
17
18
19
20
21
21
22
23
24
25
25
26
26
27
28
29
29
30
31
32
33
33
34
34
35
35
36
36
37
37
38
38
38
38
39
39
39
39
39
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
82
83
84
85
86
86
87
87
88
89
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 265416 | Complete left-hand front headlight | |
| 2 | 747044 | Left-hand front headlight | |
| 3 | 265415 | Complete right-hand front headlight | |
| 4 | 747038 | Right-hand front headlight | |
| 5 | 747039 | Front indicator light | |
| 6 | 747043 | Bulb | |
| 7 | 747042 | Bulb | |
| 8 | 747040 | Bulb | |
| 9 | 747041 | Bulb | |
| 10 | 226498 | Support | |
| 11 | 909379 | Support | |
| 12 | 42347 | Screw | |
| 13 | 61674 | Washer | |
| 14 | 224776 | Air filter clogging indicator | |
| 15 | 908369 | Clamp | |
| 16 | 247068 | Battery | |
| 17 | 142603 | Rubber strip | |
| 18 | 247641 | Fixing clamp | |
| 19 | 236816 | Fixing rod | |
| 20 | 29469 | Washer | |
| 21 | 25714 | Nut | |
| 22 | 184036 | Screw | |
| 23 | 86504 | Clamp | |
| 24 | 228547 | Support | |
| 25 | 54951 | Screw | |
| 26 | 63351 | Washer | |
| 27 | 228546 | Support | |
| 28 | 223766 | Complete right rear light | |
| 29 | 564744 | Rear light glass | |
| 30 | 223767 | Complete left rear light | |
| 31 | 224936 | Housing | |
| 32 | 224938 | Housing | |
| 33 | 225809 | Seal | |
| 34 | 226606 | Black screw | |
| 35 | 225746 | Black washer | |
| 36 | 58528 | Nut | |
| 37 | 61674 | Washer | |
| 38 | 563883 | Bulb | |
| 39 | 563884 | Bulb | |
| 40 | 224759 | Rotating beacon light | |
| 41 | 192415 | Support | |
| 42 | 466247 | Bulb | |
| 43 | 57448 | Mastic | |
| 44 | 265418 | Complete left-hand front headlight uk | |
| 45 | 747046 | Left-hand front headlight | |
| 46 | 265417 | Complete right-hand front headlight uk | |
| 47 | 747045 | Right-hand front headlight | |
| 48 | 54232 | Nut | |
| 49 | 241976 | Strain-gage | |
| 50 | 20125 | Horn | |
| 51 | 54951 | Screw | |
| 52 | 42325 | Washer | |
| 53 | 76925 | Reversing sound alarm | |
| 54 | 46668 | Screw | |
| 55 | 29469 | Washer | |
| 56 | 174132 | Washer | |
| 57 | 25714 | Nut | |
| 58 | 226997 | Support | |
| 59 | 194492 | Clamp | |
| 60 | 54951 | Screw | |
| 61 | 61674 | Washer | |
| 62 | 285540 | Support | |
| 63 | 46668 | Screw | |
| 64 | 174132 | Washer | |
| 65 | 243482 | Relay | |
| 66 | 25713 | Screw | |
| 67 | 174132 | Washer | |
| 68 | 243479 | Fuse box | |
| 69 | 245293 | Cover | |
| 70 | 245294 | Fastening lug | |
| 71 | 245295 | Fuse puller | |
| 72 | 243481 | Fuse | |
| 73 | 243480 | Fuse | |
| 74 | 25713 | Screw | |
| 75 | 174132 | Washer | |
| 82 | 261123 | Profile seal | |
| 83 | 233990 | Profile seal | |
| 84 | 274693 | Support | |
| 85 | 274694 | Support | |
| 86 | 63547 | Screw | |
| 87 | 42231 | Washer | |
| 88 | 63351 | Washer | |
| 89 | 907727 | Cap |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
