Каталог запасных частей к технике: MANITOU MT-X1740SLTS3-E3. ENGINE-TRANSMISSION ADAPTATION (Combustible circuit)
1
2
3
4
5
6
7
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
39
39
40
40
41
42
43
44
45
46
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 189535 | Plug | |
| 2 | 189536 | Watertight seal | |
| 3 | 216031 | Support | |
| 4 | 42347 | Screw | |
| 5 | 42325 | Washer | |
| 6 | 225200 | Plug | |
| 7 | 9859 | Clamp | |
| 8 | 209090 | Sleeve | |
| 9 | 31468 | Clamp | |
| 10 | 78218 | Sleeve | |
| 11 | 209091 | Plate | |
| 12 | 238448 | Seal | |
| 13 | 57446 | Screw | |
| 14 | 42325 | Washer | |
| 15 | 202994 | Indicator | |
| 16 | 187485 | Rubber seal | |
| 17 | 167981 | Screw | |
| 18 | 187294 | Washer | |
| 19 | 129397 | Screw | |
| 20 | 3411 | Copper joint | |
| 21 | 271559 | Hose | |
| 22 | 271543 | Hose | |
| 23 | 129397 | Screw | |
| 24 | 3411 | Copper joint | |
| 25 | 271560 | Hose | |
| 26 | 271546 | Hose | |
| 27 | 242592 | Clamp | |
| 28 | 249209 | Clamp | |
| 29 | 168863 | Half clamp | |
| 30 | 168494 | Protection plate | |
| 31 | 61674 | Washer | |
| 32 | 18787 | Screw | |
| 33 | 21980 | Clamp | |
| 34 | 254561 | Fuel filter | |
| 35 | 706497 | Fuel pre-filter | |
| 36 | 747027 | Water separator bowl | |
| 37 | 476171 | Plug | |
| 38 | 265688 | Support | |
| 39 | 42232 | Washer | |
| 40 | 5804 | Screw | |
| 41 | 63545 | Screw | |
| 42 | 29437 | Washer | |
| 43 | 271542 | Hose | |
| 44 | 908948 | Plate | |
| 45 | 73208 | Screw | |
| 46 | 61674 | Washer | |
| 47 | 54242 | Nut |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
