Каталог запасных частей к технике: MANITOU MT-X1235STS3-E3. CAB (DETALIS)
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
21
22
23
23
23
24
24
25
25
26
27
28
29
30
31
32
33
34
35
36
37
37
38
38
39
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
58
59
59
60
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
74
75
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 702961 | Door | |
| 2 | 199961 | Greaser | |
| 3 | 798099 | Left-hand hinge | |
| 4 | 199963 | Pivot pin | |
| 5 | 184036 | Screw | |
| 6 | 564618 | Mounting kit | |
| 7 | 208868 | Glass | |
| 8 | 600940 | Retainer | |
| 9 | 563829 | Insert | |
| 10 | 199978 | Screw | |
| 11 | 551577 | Hook | |
| 12 | 551890 | Panel | |
| 13 | 551575 | Panel | |
| 14 | 551576 | Cover | |
| 15 | 551893 | Seal | |
| 16 | 67647 | Handle | |
| 17 | 741530 | Nut | |
| 18 | 196951 | Screw | |
| 19 | 61674 | Washer | |
| 20 | 255143 | Black screw | |
| 21 | 205250 | Washer | |
| 22 | 798096 | Half hinge | |
| 23 | 72437 | Ring | |
| 24 | 61674 | Washer | |
| 25 | 255143 | Black screw | |
| 26 | 201935 | Hinge | |
| 27 | 72436 | Pin | |
| 28 | 183402 | Thickness | |
| 29 | 551579 | Lower door, stripped | |
| 30 | 190732 | Screw | |
| 31 | 184036 | Screw | |
| 32 | 72437 | Ring | |
| 33 | 72436 | Pin | |
| 34 | 929629 | Belt | |
| 35 | 203452 | Half hinge | |
| 36 | 61674 | Washer | |
| 37 | 199961 | Greaser | |
| 38 | 199963 | Pivot pin | |
| 39 | 61674 | Washer | |
| 40 | 255143 | Black screw | |
| 41 | 551889 | Seal | |
| 42 | 72476 | Lock | |
| 43 | 706997 | Washer | |
| 44 | 551582 | Nut | |
| 45 | 255143 | Black screw | |
| 46 | 551584 | Plug | |
| 47 | 551585 | Spacer | |
| 48 | 551583 | Lock | |
| 49 | 174132 | Washer | |
| 50 | 190807 | Screw | |
| 51 | 187435 | Screw | |
| 52 | 794727 | Lock | |
| 53 | 750068 | Screw | |
| 54 | 25758 | Nut | |
| 55 | 185363 | Rod | |
| 56 | 196951 | Screw | |
| 58 | 941510 | Lock | |
| 59 | 485980 | Nut | |
| 60 | 184035 | Nut | |
| 61 | 28959 | Washer | |
| 62 | 562606 | Insert | |
| 63 | 184036 | Screw | |
| 64 | 747343 | Seal | |
| 65 | 201935 | Hinge | |
| 66 | 203452 | Half hinge | |
| 67 | 744649 | Washer | |
| 68 | 747344 | Adhesive | |
| 69 | 233285 | Panel | |
| 70 | 233286 | Panel | |
| 71 | 702962 | Door | |
| 72 | 747345 | Door | |
| 73 | 184818 | Ignition key | |
| 74 | 744649 | Washer | |
| 75 | 744649 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
