Каталог запасных частей к технике: Lonking (LongGong) LG50CVII.00I. FRAME ASSEMBLY (30810900337)
1
1
2
2
2
3
4
5
6
7
8
9
10
11
12
13
13
14
14
15
16
17
18
19
20
20
21
21
22
23
24
25
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42
42
43
43
43
44
44
44
45
46
47
48
49
50
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 51204111214 | Bolt | |
| 2 | 51401110107 | Spring lock washer | |
| 3 | 30810100704 | Press plate | |
| 4 | 60903000037 | Articulated pin | |
| 5 | 51203112714 | Bolt M12x110 | |
| 6 | 30810100703 | Upper bearing cover | |
| 7 | 56161012401 | Seal ring FB75x100x12 | |
| 8 | 60980000184 | Adjusting pad | |
| 9 | 52324001301 | Bearing 32215 | |
| 10 | 30810100700 | Upper shaft sleeve | |
| 11 | 51307001119 | Nut | |
| 12 | 30810100705 | End cover | |
| 13 | 51401150107 | Washer | |
| 14 | 51204153714 | Bolt M20x35 | |
| 15 | 56161006501 | Seal ring FB85x110x12 | |
| 16 | 30810100702 | Lower bearing cover | |
| 17 | 30810100701 | Lower shaft sleeve | |
| 18 | 30810100797 | Lower end cover | |
| 19 | 51204133314 | Bolt M16x50 | |
| 20 | 51401130107 | Spring lock washer | |
| 21 | 51421130115 | Washer | |
| 22 | 30810000562 | Welding of oil tank fixing seat | |
| 23 | 56201000301 | Oil cup | |
| 24 | 30890900237 | Rear steering pin shaft welding | |
| 25 | 51204132514 | Bolt | |
| 26 | 30810000965 | Rear frame welding | |
| 27 | 30810000705 | Welding of oil inlet pipe 2 of subframe | |
| 28 | 60980000179 | Washer 10 | |
| 29 | 30893100787 | Bolt | |
| 30 | 30810000704 | Welding of oil inlet pipe 1 of subframe | |
| 31 | 30863900215 | Welding of swing span | |
| 32 | 30810101358 | Swing span adjusting shim | |
| 33 | 30810101445 | Copper gasket | |
| 34 | 60905000048 | Auxiliary frame pin shaft sleeve | |
| 35 | 30810000449 | Welding of swing span pin | |
| 36 | 51421150115 | Washer | |
| 37 | 30810100600 | Power switch Mounting plate | |
| 38 | 51204081014 | Bolt | |
| 39 | 51421080115 | Plain washer | |
| 40 | 51401080107 | Spring lock washer | |
| 41 | 30810102361 | Buzzer fixing plate | |
| 42 | 51204091014 | Bolt | |
| 43 | 51401090107 | Washer | |
| 44 | 51421090115 | Washer | |
| 45 | 51421100115 | Plain washer | |
| 46 | 60911010971 | Filler pipe clip assembly | |
| 47 | 30810102929 | Cover plate bracket | |
| 48 | 51204101214 | Bolt | |
| 49 | 51401100107 | Spring lock washer | |
| 50 | 30810101356 | Rear sleeve for steering cylinder |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
