Каталог запасных частей к технике: Lonking (LongGong) CDM-860.00. Emergency and Parking Brake System
1
2
3
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LG50EX.09.02 | Parking brake chamber | |
| 2 | LG860.09.01 | Parking brake chamber securing bracket | |
| 3 | GB/T5783-2000 | Bolt | |
| 4 | GB/T97.1-2002 | Washer | |
| 5 | GB/T93-1987 | Washer | |
| 6 | 90C-C/8/8-I-L1800 | Hose from protection valve | |
| 7 | LG856.09.02 | Manual brake valve | |
| 8 | LG856.09-001 | Plug | |
| 9 | L1QH-16 | Connector | |
| 10 | JB/T982-1977 | Washer | |
| 11 | L1QH-16-22 | Adapter | |
| 12 | JB/T982-1977 | Washer | |
| 13 | LG856.09.01 | Parking brake air tank assembly | |
| 14 | C-C/8/8-I-L3200 | Hose from manual brake air tank to manual brake valve | |
| 15 | C-C/8/8-I-L3200 | Hose from manual brake air tank to manual brake valve | |
| 16 | LG50EX.09-002 | Manual brake valve air inlet connector | |
| 17 | LG50EX.09-001 | Manual brake valve air outlet connector | |
| 18 | L1QH-16-12 | Connector | |
| 19 | GB/T5783-2000 | Bolt | |
| 20 | GB/T97.1-2002 | Washer | |
| 21 | GB/T93-1987 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
