Каталог запасных частей к технике: Lonking (LongGong) CDM-833. CABLING CAB (30815000310)
1
2
3
3
4
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 60404011580 | Headlamp | |
| 2 | 51204091014 | Bolt | |
| 3 | 51421090115 | Washer | |
| 4 | 51401090107 | Washer | |
| 5 | 30815000256 | Installation assembly of fan heater | |
| 6 | 60400000790 | A/C assembly | |
| 7 | 60400000569 | Front windscreen wiper assembly | |
| 8 | 51204091114 | Bolt | |
| 9 | 51421110115 | Plain washer | |
| 10 | 51401110107 | Spring lock washer | |
| 11 | 51204111314 | Bolt | |
| 12 | 51420080121 | Plain washer | |
| 13 | 51401080107 | Spring lock washer | |
| 14 | 51204081014 | Bolt | |
| 15 | 60400002244 | Independent assembly | |
| 16 | 60400002246 | Independent assembly | |
| 17 | 60980000071 | Cold start system | |
| 18 | 60400000576 | Fuse box assembly | |
| 19 | 60400000572 | Rear windscreen wiper assembly | |
| 20 | 60400000792 | Control console harness | |
| 21 | 60400000551 | Rocker switch | |
| 22 | 60400000736 | Warning lamp switch | |
| 23 | 60400000737 | Wiper switch | |
| 24 | 60400000670 | 12V charging rack | |
| 25 | 60402050240 | Ceiling lamp | |
| 26 | 60401050021 | Electric fan | |
| 27 | 51421080115 | Plain washer | |
| 28 | 51158190704 | Screw M6x25 | |
| 29 | 60400000727 | MP3 Player | |
| 30 | 60400000546 | Cab harness | |
| 31 | 60400000553 | Warning lamp | |
| 32 | 51158170404 | Screw | |
| 33 | 51401070107 | Washer | |
| 34 | 51421070115 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
