Каталог запасных частей к технике: Lonking (LongGong) CDM-816. Steering hydraulic system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LG816.06.01 | STEERING CYLINDER | |
| 2 | 90H-270-90H/13/14-II- L1350 | HOSE FROM STEERING GEAR TO STEERING CYLINDER BIG CHAMBER | |
| 3 | 70H-290-90H/13/14-II- L950 | HOSE FROM STEERING GEAR TO STEERING CYLINDER SMALL CHAMBER | |
| 4 | 90H-225-90H/13/14-II- L610 | HOSE FROM PRIORITY VALVE TO STEERING GEAR | |
| 5 | LG816.06-001 | PRIORITY VALVE PORT CF CONNECTOR | |
| 6 | JB1002-77 | Washer | |
| 7 | 90H-270-90H/13/14-II- L580 | STEERING GEAR OIL RETURN HOSE | |
| 8 | 90H-270 ° -90H/8/8-II-L600 | LS SENSING HOSE | |
| 9 | GB3733.2-83 | CONNECTOR | |
| 10 | JB1002-77 | Washer | |
| 11 | LG816.06-003 | STEERING GEAR CONNECTOR | |
| 12 | JB1002-77 | Washer | |
| 13 | LG816.06.02 | STEERING GEAR ASSEMBLY | |
| 14 | GB/T5783 | Bolt | |
| 15 | GB/T93 | Washer | |
| 16 | GB/T97.1 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
