Каталог запасных частей к технике: Lonking (LongGong) CDM-6485H. PILOT PIPING II
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 17272000654 | HOSE ASS'Y | |
| 2 | 60911010628 | REDUCER UNION | |
| 3 | 60911010009 | STRAIGHT CONNECTOR | |
| 4 | 60911010109 | THREE-WAY CONNECTOR | |
| 5 | 17272006280 | HOSE ASS'Y | |
| 6 | 60911010003 | STRAIGHT CONNECTOR | |
| 7 | 60304000338 | PILOT VALVE | |
| 8 | 51421100121 | WASHER 10 | |
| 9 | 51204101122 | BOLT M10x25 | |
| 10 | 17272000381 | HOSE ASS'Y | |
| 11 | 60911010024 | RIGHT-ANGLE CONNECTOR | |
| 12 | 60911010017 | END STRAIGHT CONNECTOR | |
| 13 | 17272003241 | HOSE ASS'Y | |
| 14 | 17272003560 | HOSE ASS'Y | |
| 15 | 60911011084 | PRESSURE THREE-WAY CONNECTOR | |
| 16 | 60911010038 | THREE-WAY CONNECTOR | |
| 17 | 60911010113 | RIGHT ANGLE CONNECTOR | |
| 18 | 60911010599 | THREE-WAY CONNECTOR | |
| 19 | 17272003477 | HOSE ASS'Y | |
| 20 | 17272006498 | HOSE ASS'Y | |
| 21 | 17272000580 | HOSE ASS'Y | |
| 22 | 60911010037 | THREE-WAY CONNECTOR | |
| 23 | 17272000727 | HOSE ASS'Y | |
| 24 | 17272000732 | HOSE ASS'Y | |
| 25 | 60911010620 | STRAIGHT CONNECTOR | |
| 26 | 17272004333 | HOSE ASS'Y | |
| 27 | 60911010018 | END STRAIGHT CONNECTOR | |
| 28 | 60911010082 | STRAIGHT CONNECTOR | |
| 29 | 17272000369 | HOSE ASS'Y | |
| 30 | 17272003481 | HOSE ASS'Y | |
| 31 | 17272006726 | HOSE ASS'Y | |
| 32 | 60911010002 | STRAIGHT CONNECTOR | |
| 33 | 17272006691 | HOSE ASS'Y | |
| 34 | 17272000378 | HOSE ASS'Y | |
| 35 | 17272000375 | HOSE ASS'Y |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
