Каталог запасных частей к технике: Lonking (LongGong) CDM-6365H. MAIN PUMP LINES
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LG6230.05.01.05 | DAMPING WASHER | |
| 2 | GB/T5783 | Bolt | |
| 3 | GB/T96.1 | Washer | |
| 4 | LG6230.05.01.04 | MOUNTING BOARD | |
| 5 | GB/T97.1 | Washer | |
| 6 | GB/T5782 | Bolt | |
| 7 | MDM101CD1CB372X | PRESSURE FILTER | |
| 8 | 1B-08WD | 1B-08WD | |
| 9 | F481CACF151508-900 | HOSE ASSY | |
| 10 | F421CACF151510-1300 | HOSE ASSY | |
| 11 | 1BH-08-18 | 1BH-08-18 | |
| 12 | LG6360.05.01.02 | A1 HOSE | |
| 13 | O222 | O-RING d37.69x3.53 | |
| 14 | F481CACA121206-1100 | HOSE ASSY | |
| 15 | F7816N6N20(SL120) 2020-1600-27O° | HOSE ASSY | |
| 16 | 1BH-06-14WD | Straight joint | |
| 17 | BJS-08-04 | THREE-WAY CONNECTOR | |
| 18 | F481CACF080804-650 | HOSE ASSY | |
| 19 | F481CACF121206-700 | HOSE ASSY | |
| 20 | LG6360.05.01-07 | SUPPORT | |
| 21 | LG6360.05.01-08 | PIPE CLAMP | |
| 22 | LG6360.05.01-09 | Rubber sleeve | |
| 23 | F7816N6N20(SL120)20 (SL120)20-1070-27O° | HOSE ASSY | |
| 24 | LG6360.05.01.01 | A2 HOSE | |
| 25 | LG6360.05B.01-01 | OIL SUCTION HOSE | |
| 26 | STBH-132 | CLAMP d122-130 | |
| 27 | LG6360.05.01.03 | OIL SUCTION HOSE | |
| 28 | AS254 | O-RING d139.29x3.53 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
