Каталог запасных частей к технике: Lonking (LongGong) CDM-6365H. BREAKER LINES
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 1BG-16 B2351 | END STRAIGHT CONNECTOR | |
| 2 | 2B9-16 | RIGHT ANGLE ADJUSTING CONNECTOR | |
| 3 | M2M2HK-16 | FLANGE COMPONENT | |
| 4 | F7316A15161616-1900 | HOSE ASSY | |
| 5 | F481CE15281616-2200 | HOSE ASSY | |
| 6 | M1M1HK-16 | FLANGE | |
| 7 | LG6360.15-02 | PLATE | |
| 8 | GB/T5783 | Bolt | |
| 9 | GB/T97.1 | Washer | |
| 10 | LG6360.20-01 | TRANSITION BLOCK | |
| 11 | LG6360.15-05 | PLATE | |
| 12 | LG6360.15-04 | RUBBER PAD | |
| 13 | LG6360.20.01 | RIGHT PIPE | |
| 14 | LG6360.20.02 | LEFT PIPE | |
| 15 | OR32.92X3.53 | O-RING | |
| 16 | GB/T70.1 | Screw | |
| 17 | GB/T97.1 | Washer | |
| 18 | LG6360.20.03 | PIPE 1 | |
| 19 | LG6360.20-02 | BLOCK | |
| 20 | LG6360.20-03 | PIPE CLAMP | |
| 21 | GB/T5783 | Bolt | |
| 22 | F7811519161616-1800 | HOSE ASSY | |
| 23 | LG63600.20.04 | ARM PIPE | |
| 24 | EGE-G1-16WD | END STRAIGHT COMBINED CONNECTOR | |
| 25 | 1FG-16WD | END STRAIGHT CONNECTOR | |
| 26 | 9F-16 | INTERNAL THREAD PLUG | |
| 27 | BKH-G1 | HIGH PRESSURE BALL VALVE | |
| 28 | 1BG-06-04 | END STRAIGHT CONNECTOR | |
| 29 | F481CACF121206-1650 | HOSE ASSY | |
| 30 | F481CACF121206-1750 | HOSE ASSY | |
| 31 | GB/T97.1 | Washer | |
| 32 | GB/T5872 | BOLT M6x40 | |
| 33 | WYS-02 | SHUTTLE VALVE BLOCK | |
| 34 | F481CACF121206-1000 | HOSE ASSY | |
| 35 | F481CACF121206-1800 | HOSE ASSY |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
