Каталог запасных частей к технике: Lonking (LongGong) CDM-6065. MAIN PUMP LINES
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 60911010009 | STRAIGHT CONNECTOR | |
| 2 | 17272000425 | HOSE ASS'Y | |
| 3 | 60911010002 | STRAIGHT CONNECTOR | |
| 4 | 17272000424 | HOSE ASS'Y | |
| 5 | 60911010026 | RIGHT ANGLE CONNECTOR | |
| 6 | 17272000072 | HOSE ASS'Y | |
| 7 | 17272000078 | HOSE ASS'Y | |
| 8 | 60911010021 | STRAIGHT CONNECTOR | |
| 9 | 16856063001 | MAIN PUMP ASS'Y | |
| 10 | 60911010022 | STRAIGHT CONNECTOR | |
| 11 | 30605100048 | CONNECTOR, DRAIN PORT | |
| 12 | 30605100048 | SCREW M10x80 | |
| 13 | 51401100122 | WASHER 12 | |
| 14 | 56145009505 | O-RING 35.5x3.55 | |
| 15 | 17272004918 | HOSE ASS'Y | |
| 16 | 60911010003 | STRAIGHT CONNECTOR | |
| 17 | 30605000019 | CONNECTOR, SUCTION PORT | |
| 18 | 51139230308 | SCREW M12x30 | |
| 19 | 51401110122 | WASHER 12 | |
| 20 | 56900000503 | O-RING 56.74x3.53 | |
| 21 | 60911010020 | STRAIGHT CONNECTOR | |
| 22 | 60911013252 | HOSE 58-180 | |
| 23 | 60911010001 | STAINLESS STEEL CLAMP 57-79 | |
| 24 | 30605100047 | U BOLT 60 | |
| 25 | 30605000004 | ELBOW PIPE 2 | |
| 26 | 60911013252 | HOSE 58-260 | |
| 27 | 51421110121 | WASHER 12 | |
| 28 | 51301000519 | NUT M12 | |
| 29 | 60911010008 | STRAIGHT CONNECTOR | |
| 30 | 60911013253 | HOSE 58-180 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
