Каталог запасных частей к технике: Lonking (LongGong) CDM-514D. Electric system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LG520D.26-001 | Starting relay | |
| 2 | LG512D.26.78 | Water temperature sensor | |
| 3 | LG853.15.28 | Main power switch | |
| 4 | N120 | Battery | |
| 5 | LG520D.26.04 | Battery harness | |
| 6 | LG520D.26.06 | Car body arness | |
| 7 | LG520D.26.02 | Panel harness | |
| 8 | LG512D.26.79 | Oil pressure sensor | |
| 9 | LG520D.26-014 | Speed sensor | |
| 10 | LG520D.26.03 | Panel, switch, electric parts assembly | |
| 11 | LG520D.26.05 | Board & parts harness assembly | |
| 12 | LG520D.26-004 | Fuse box | |
| 13 | LG520D.26-005 | Flasher | |
| 14 | LG520D.26-006 | Flameout switch | |
| 15 | LG520D.26-007 | Neutral relay | |
| 16 | LG520D.26-008 | Braking relay | |
| 17 | LG520D.26-009 | Time relay | |
| 18 | LG520D.26-010 | Upper & lower beam relay | |
| 19 | LG520D.26-011 | Vibrating Relay | |
| 20 | LG520D.26-012 | Singal fuse | |
| 21 | LG816.15.09 | ELECTRICAL HORN | |
| 22 | LG810.15.07 (A) | Grouped Lamps |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
