Каталог запасных частей к технике: Lonking (LongGong) CDM-312. Diesel Engine System (LG307)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LG308.05.06 | End joint bearing | |
| 2 | GB/T6170-2000 | Nut | |
| 3 | LG307.01.21 | Throttle flexible shaft | |
| 4 | LG308.01.01 | Manual and throttle assembly | |
| 5 | JB/T8870-1999 | Hose clamp | |
| 6 | LG307.01-003 | Air filter air outlet hose | |
| 7 | JB/T8870-1999 | Hose clamp | |
| 8 | G068661 | Air filter assembly | |
| 9 | X770062 | Alarm | |
| 10 | P778810 | Clamp | |
| 11 | LG307.01.06 | Air filter bracket | |
| 12 | GB/T5783-2000 | Bolt | |
| 13 | GB/T6170-2000 | Nut | |
| 14 | LG307.01-013 | Air filter air inlet hose | |
| 15 | JB/T982 | Combined washer | |
| 16 | 700M-14 | Link bolt M14x1.5 | |
| 17 | 70011-14-05A30 d 8x2000 | Hose | |
| 18 | LG308.15-008 | Line clamp | |
| 19 | LG307.01.03 | Hose | |
| 20 | GB/T5781-2000 | Bolt | |
| 21 | GB/T97.1-2002 | Washer | |
| 22 | GB/T93 | Washer | |
| 23 | 1G311-4335 | Oil-water separater | |
| 24 | JB/T8870 | Pipe clamp | |
| 25 | LG307.01.19 | Throttle flexible shaft bracket | |
| 26 | GB/T97 | Washer | |
| 27 | GB/T93 | Washer | |
| 28 | GB/T5783 | Bolt | |
| 29 | LG307.01-014 | Bush | |
| 30 | GB/T5783 | Bolt | |
| 31 | GB/T5782-2000 | Bolt | |
| 32 | LG307.01-005 | Washer | |
| 33 | NT50-2.5-01 | Rear shock absorber | |
| 34 | GB/T6170-2000 | Nut | |
| 35 | GB/T5786-2000 | Bolt | |
| 36 | GB/T5786-2000 | Bolt | |
| 37 | LG307.01.11 | Diesel engine left rear bracket | |
| 38 | LG307.01-007 | Left rear washer | |
| 39 | LG307.01.02 | Hose | |
| 40 | 1C011-43013 | Fuel filter | |
| 41 | LG307.01.13 | Hose | |
| 42 | LG307.01.05 | Hose | |
| 43 | 1G065-42361 | T-connector | |
| 44 | 14971-4251 | Spring clamp | |
| 45 | LG307.01.02 | Hose | |
| 46 | L1CH-22 | Metric through transition connector | |
| 47 | L9C-22T | Metric through transition connector | |
| 48 | 10411-22/20491-22Tx1T10x1000 | Oil drain hose | |
| 49 | LG308.01-018 | Oil pipe transition connector | |
| 50 | GB/T5786-2000 | Bolt | |
| 51 | GB/T93-1987 | Washer | |
| 52 | LG307.01.01 | Diesel engine leftfront support | |
| 53 | 07Y-03-1000A-1140 | Front shock absorber | |
| 54 | GB/T5782-2000 | Bolt | |
| 55 | 512882 | Coupling shaft coupling assembly | |
| 56 | GB/T5786-2000 | Bolt | |
| 57 | LG307.01-004 | Engine connecting disc | |
| 58 | LG307.01.18 | Series pump bracket | |
| 59 | GB/T93-1987 | Washer | |
| 60 | GB/T5782-2000 | Bolt | |
| 61 | GB/T5783-2000 | Bolt | |
| 62 | LG307.01.07 | Diesel engine right front bracket | |
| 63 | V2403-M-T-E3B-YCI-1 | Diesel engine assembly | |
| 64 | LG307.01-006 | Right rear washer | |
| 65 | LG307.01.10 | Diesel engine right rear bracket | |
| 66 | GB/T5785-2000 | Bolt | |
| 67 | LG307.01.09 | Compressor assembly | |
| 68 | GB11544-89 | Belt | |
| 69 | LG307.01-009 | Water tank outlet hose | |
| 70 | LG307.01.17 | Steel tube | |
| 71 | LG307.01.12 | Wind cover weldment | |
| 72 | LG307.01.15 | Hose support plate | |
| 73 | DIN3016-1 | Clamp | |
| 74 | GB/T5782-2000 | Bolt | |
| 75 | GB/T97.1-2002 | Washer | |
| 76 | LG308.01.13 | Water tank lower bracket | |
| 77 | GB/T96.1-2002 | Washer | |
| 78 | GB/T6170-2000 | Nut | |
| 79 | GB/T93-1987 | Washer | |
| 80 | LG308.01-010 | Bush | |
| 81 | GB/T5781-2000 | Bolt | |
| 82 | LG308.01.06 | Radiator assembly | |
| 83 | CDM606.01.01.01 | Vice water tank | |
| 84 | LG308.01-003 | Water tank right upper bracket | |
| 85 | GB/T97.1-2002 | Washer | |
| 86 | GB/T5783-2000 | Bolt | |
| 87 | LG308.01-006 | Water tank left upper bracket | |
| 88 | LG307.01-008 | Water tank inlet hose | |
| 89 | LG307.01.04 | Muffle assembly | |
| 90 | 17326-12231 | Muffle seal gasket | |
| 91 | 16483-12321 | Muffle transition connector |
