Каталог запасных частей к технике: Lonking (LongGong) CDM-308. Electrical System
1
2
3
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
25
25
25
26
26
26
26
26
26
26
26
26
26
27
27
27
27
27
27
27
27
27
28
28
28
28
28
29
29
29
30
31
32
33
34
35
36
36
37
38
38
39
39
40
40
41
42
43
44
44
45
46
47
47
47
47
48
48
48
48
49
49
49
50
50
51
51
51
52
53
54
55
56
57
58
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LG8380.15.15 | Stroke switch | |
| 2 | GB/T818 | Screw | |
| 3 | GB/T93 | Washer | |
| 4 | GB/T97.1 | Washer | |
| 5 | GB/T6170 | Nut | |
| 6 | LG308.15.01.01 | Lift arm and Tool harness | |
| 7 | GB/T818 | Screw | |
| 8 | GB/T93 | Washer | |
| 9 | GB/T97.1 | Washer | |
| 10 | GB/T6170 | Nut | |
| 11 | LG8380.15.16 | Wiper washing assembly | |
| 12 | GB/T818 | Screw | |
| 13 | GB/T6170 | Nut | |
| 14 | GB/T818 | Screw | |
| 15 | LG308.15-004 | Working lamp | |
| 16 | LG308.15.03 | Instrument controller assembly | |
| 17 | 6JK.007.232-001 | Key switch | |
| 18 | GB/T70.1 | Screw | |
| 19 | LG312.15-003 | Steering lamp | |
| 20 | LG308.15-003 | Ceiling lamp | |
| 21 | LG312.15-004 | Warning lamp | |
| 22 | LG312.15.01 | Control-box assembly | |
| 23 | LG308.15-002 | Closed switch | |
| 24 | LG307.15.04 | Air conditioning assembly | |
| 25 | GB/T5783 | Bolt | |
| 26 | GB/T93 | Washer | |
| 27 | GB/T96.1 | Washer | |
| 28 | GB/T5783 | Bolt | |
| 29 | GB/T6170 | Nut | |
| 30 | GB/T5783 | Bolt | |
| 31 | LG308.15.01.02 | Milling harness | |
| 32 | LG308.15.01.03 | Snow blower harness | |
| 33 | LG312.15.02 | Electrical switch assembly | |
| 34 | LG503DC.26.0637 | Start relay | |
| 35 | 60980001343 | Plug | |
| 36 | LG308.15-014 | Back-up alarm switch | |
| 37 | LG853.15.26 | Battery | |
| 38 | GB/T5783 | Bolt | |
| 39 | GB/T97.1 | Washer | |
| 40 | GB/T93 | Washer | |
| 41 | GB/T6170 | Nut | |
| 42 | YT306J-9/16-18UNF | Oil temperature switch | |
| 43 | YT310B | Up the oil switch | |
| 44 | LG308.15-006 | Line clamp | |
| 45 | LG308.15-001 | Fuel oil level sensor | |
| 46 | GB/T818 | Screw | |
| 47 | GB/T97.1 | Washer | |
| 48 | GB/T93 | Washer | |
| 49 | LG312.15-002 | Red light show wide | |
| 50 | GB/T818 | Screw | |
| 51 | LG308.15-010 | Line clamp | |
| 52 | LG308.15-012 | Left rear combined lamp | |
| 53 | LG308.15-013 | Right rear combined lamp | |
| 54 | LG8380.15.18 | Back-up alarm buzzer | |
| 55 | GB/T97.1 | Washer | |
| 56 | DL124EG | Speaker | |
| 57 | LG308.15-008 | Line clamp | |
| 58 | LG308.15-009 | Line clamp |
