Каталог запасных частей к технике: Lonking (LongGong) CDM-1185. Transmission Connect (I) (CDM1165)
1
2
3
4
5
6
7
8
8
8
8
8
9
10
11
11
12
12
13
13
14
14
14
14
15
15
16
16
17
17
18
18
19
20
21
22
23
25
26
27
28
29
29
30
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LG1165.04.12 | Mechanical transmission | |
| 2 | LG1185.04-002 | Spline sleeve | |
| 3 | LG1185.04-003 | Seal gasket | |
| 4 | LG1165.04-001 | Transition plate | |
| 5 | GB93-87 | Washer | |
| 6 | GB5783 | Bolt | |
| 7 | LG1185.04-004 | Seal gasket | |
| 8 | GB93-87 | Washer | |
| 9 | GB5783 | Bolt | |
| 10 | LG1185.04.10 | Gear pump | |
| 11 | GB3452.1 | O-ring | |
| 12 | LG1185.04-013 | Connector | |
| 13 | LG1185.04.40 | Pressure connector | |
| 14 | GB5783-86 | Bolt | |
| 15 | GB3452.1 | O-ring | |
| 16 | LG1185.04-012 | Connector | |
| 17 | GB5782-86 | Bolt | |
| 18 | GB93-87 | Washer | |
| 19 | LG1185.04-010 | Connector | |
| 20 | GB3452.1 | O-ring | |
| 21 | LG1165.04.11 | Gear pump | |
| 22 | GB3452.1 | O-ring | |
| 23 | LG1185.04-011 | Connector | |
| 25 | GB5783-86 | Bolt | |
| 26 | GB97.1-85 | Washer | |
| 27 | LG1185.04-031 | Washer | |
| 28 | LG1185.04-005 | Seal gasket | |
| 29 | GB97.2-85 | Washer | |
| 30 | GB5783-86 | Bolt | |
| 31 | LG1185.04.01.02 | Right Bracket | |
| 32 | GB893.1-86 | Circlip | |
| 33 | LG1185.04-006 | Connecting disc |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
