46C3428 BATTERY WIRING
Каталог запасных частей к технике: LiuGong CLG-B160. 46C3428 BATTERY WIRING
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
Ammann
BOMAG
CARMIX
CASE IH
Changlin
ChengGong
Dimex
Doosan
DYNAPAC
Foton
HAMM
Hidromek
Hitachi
Hyundai
JCB
JLG
John Deere
Komatsu
LIEBHERR
LiuGong
Lonking (LongGong)
Luneng
MANITOU
Mitsuber
New Holland
PENGPU
RM-Terex
SANY
SDLG
SEM
Shantui
Shehwa HBXG
Soosan
TIGARBO
VOGELE
Volvo
WAY
WIRTGEN
XCMG
XGMA
Xiamen
YTO
Yuchai
Zoomlion
Автокран
АЗСМ
Алтайлесмаш
Амкодор
АОМЗ
Атек
АТЗ
Балканкар Рекорд
БелАЗ
Беловеж
Борекс
Брянский Арсенал
Булат
ВЭКС
ГАЗ
Геомаш
Гидромаш
Донекс
Дормаш
Дормашина
Дорэлектромаш
ДЭЗ
ЕлАЗ
ЗЗГТ
Ижнефтемаш
Канаш-электрокар
КЗКТ
ККЗ
Клевер
Клинцовский автокрановый завод
КМЗ
КМЗ 1 Мая
Ковровец
Коммаш
Кранэкс
КЭЗ
КЭМЗ
ЛЗА
МАЗ
МЗИК
МЗКМ
МЗКТ
Михневский РМЗ
МоАЗ
Мозырский МЗ
МТЗ
ОЗП
Онежец
ПАО "ТЗА"
ППС Детва
Промтрактор
ПТЗ
Раскат
СпецАгрегат
ТВЭКС
ТТМ
УВЗ
Угличмаш
УЗТМ
ХТЗ
ЧЗКМ
ЧСДМ
ЧТЗ
ЭКСКО
ЭКСМАШ
ЮрМаш
Модель
Не выбрано
CLG 425 (2010)
CLG 777A-S (2010)
CLG-2040H (2045H, 2050HL, 2040H, 2045H, 2050HL) (2016)
CLG-220 (2008)
CLG-225 (2008)
CLG-365A (2012)
CLG-375 (2008)
CLG-375A (2008)
CLG-385A (2008)
CLG-4165 (2015)
CLG-418 (2008)
CLG-4215 (2010)
CLG-612 (2008)
CLG-614 (2010)
CLG-618 (2010)
CLG-626R
CLG-766 (2015)
CLG-766A (2012)
CLG-816G (2012)
CLG-835
CLG-835 (2015)
CLG-835H (2015)
CLG-836 (2015)
CLG-842
CLG-842
CLG-842 (2015)
CLG-855N (2015)
CLG-856 (2015)
CLG-856H (2015)
CLG-856I
CLG-862 (2015)
CLG-877 (2015)
CLG-888 (2015)
CLG-904С (2007)
CLG-915D
CLG-915D
CLG-920D
CLG-920E (2015)
CLG-922D
CLG-922LC
CLG-922LC (2008)
CLG-925 (2015)
CLG-925D (2015)
CLG-933E (2010)
CLG-B160 (2010)
Схема
>
Не выбрано
45E0965 000 DECAL GROUP
00E0823 001 ENGINE MOUNTING PARTS
00E0889 ENGINE SYSTEM (SPECIAL FOR SHANG CHAI)
00E0797 THROTTLE CONTROL LEVER
00E0797 DECELERATOR PEDAL
00E0831 THROTTLE CONTROL LEVER (SPECIAL FOR SHANG CHAI)
00E0831 DECELERATOR PEDAL (SPECIAL FOR SHANG CHAI)
00E0574 RADIATOR PIPING AND WIND BREAK
00E0837 RADIATOR PIPING AND WIND BREAK (SPECIAL FOR SHANG CHAI)
40C2434 FUEL TANK AS
00E0836 FUEL TANK (CHANG CHAI)
04E0073 TRANSFER CASE
04E0073 TRANSFER CASE
04E0073 TRANSFER CASE
04E0073 TRANSFER CASE
04E0105 TRANSFER CASE (SPECIAL FOR SHANG CHAI)
04E0105 TRANSFER CASE (SPECIAL FOR SHANG CHAI)
04E0105 TRANSFER CASE (SPECIAL FOR SHANG CHAI)
04E0105 TRANSFER CASE (SPECIAL FOR SHANG CHAI)
26E0100 001 UNIVERSAL JOINT
02E0049 TORQUE CONVERTER
02E0049 TORQUE CONVERTER
02E0049 TORQUE CONVERTER
02E0049 TORQUE CONVERTER
02E0049 TORQUE CONVERTER
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
04E0071 TRANSMISSION
26E0083 SUPPORT AND DRIVE SHAFT SYSTEM
26E0093 FINAL DRIVE
26E0093 FINAL DRIVE
26E0093 FINAL DRIVE
26E0096 FINAL DRIVE (SWAMP)
26E0096 FINAL DRIVE (SWAMP)
26E0096 FINAL DRIVE (SWAMP)
24E0052 TORQFLOW TRANSMISSION CHANGE LEVER
15E0514 TORQUE CONVERTER AND GEARBOX LINES
15E0514 TORQUE CONVERTER AND GEARBOX LINES
15E0514 TORQUE CONVERTER AND GEARBOX LINES
10E0173 STEERING LINES
10E0173 STEERING LINES
10E0197 STEERING LINES (SPECIAL FOR SHANG CHAI)
10E0197 STEERING LINES (SPECIAL FOR SHANG CHAI)
15E0515 STEERING RELIEF LINES
15E0516 TEST LINES
12C1885 STEERING VALVE
12C1896 RELIEF VALVE
11C0798 TRANSMISSION PUMP
11C0799 STEERING PUMP
53C0396 SECONDARY OIL FILTER
53C0393 PRIMARY OIL FILTER
00C1164 PUMP LINES (WITH RIPPER CONTROL)
00C1200 PUMP LINES
00C1776 PUMP LINES (ANGLE BLADE WITH RIPPER CONTROL)
00C1859 PUMP LINES (ANGLE BLADE)
00C2517 PUMP LINES (ANGLE BLADE WITH WINCH)
44C1418 BLADE LIFT LINES
44C1444 BLADE LIFT LINES (SWAMP)
44C1485 BLADE LIFT LINES
44C1683 BLADE LIFT LINES (SWAMP AND LENGTH)
44C0673 BLADE TILT LINES
44C0673 BLADE TILT LINES
44C0675 BLADE TILT LINES (SWAMP)
44C0675 BLADE TILT LINES (SWAMP)
44C0615 THREE TEETH RIPPER LINES
44C0986 WINCH LINES
21C0320 HYDRAULIC OIL TANK
21C0320 HYDRAULIC OIL TANK
21C0326 HYDRAULIC OIL TANK (WITH RIPPER CONTROL VALVE)
21C0326 HYDRAULIC OIL TANK (WITH RIPPER CONTROL VALVE)
12C2121 BLADE CONTRAL VAVLE
12C2121 BLADE CONTRAL VAVLE
12C2031 RIPPER CONTROL VAVLE
10C0892 000 RIPPER CYLINDER
11C0765 000 GEAR PUMP
45C0232 CLUTCH
20E0272 BRAKE
20E0272 BRAKE
20E0270 000 STEERING CONTROL LEVER
20E0270 000 BRAKE PEDAL AND LINKAGE
20E0270 BRAKE PEDAL AND LINKAGE
20E0270 000 BRAKE LOCK LEVER
33E0076 TRACK FRAME AS
33E0076 TRACK FRAME COVER
33E0076 RECOIL SPRING
33E0076 IDLER AS
33E0076 CARRIER ROLLER
33E0076 TRACK ROLLER
33E0078 TRACK AS
33E0077 TRACK FRAME (SWAMP)
33E0077 TRACK FRAME COVER (SWAMP)
33E0077 RECOIL SPRING (SWAMP)
33E0077 IDLER AS (SWAMP)
33E0077 CARRIER ROLLER (SWAMP)
33E0077 TRACK ROLLER (SWAMP)
33E0095 TRACK AS (SWAMP)
30E0475 MAIN FRAME AS
30E0692 STEERING CASE AND MAIN FRAME (FOREST)
30E0491 MAIN FRAME AS (SWAMP)
32E1540 STRAIGHT TILT BLADE
32E1600 BLADE ASSEMBLY
32E1600 BLADE ASSEMBLY
32E1543 STRAIGHT TILT BLADE (SWAMP)
24C0553 TRACTION FRAME
30E0467 EQUALIZE BAR
30E0473 EQUALIZE BAR (SWAMP)
32E0780 BLADE CONTROL LEVER (STRAIGHT BLADE)
32E0780 BLADE CONTROL LEVER (STRAIGHT BLADE)
32E1165 ANGLE BLADE CONTROL LEVER
32E1165 ANGLE BLADE CONTROL LINKAGE
32E1126 RIPPER CONTROL LEVER
32E1126 RIPPER CONTROL LINKAGE
32E0898 THREE TEETH RIPPER
41E0403 CAB AS
44E0481 ENGINE HOOD AS
44E0504 ENGINE HOOD AS (SPECIAL FOR SHANG CHAI)
36E0018 SAFEGUARD
22C0830 BRACKET
22C0698 BRACKET
46E0056 SEAT AS
48C0845 001, 48C0846 001 SIDE HOOD
30E0713 FENDER AS
48C1416 SHIELD A
30E0712 FENDER AS (SPECIAL FOR RIPPER)
30E0756 FENDER AS (SPECIAL FOR HYDRAULIC WINCH)
48C1472 SHIELD AS
30E0755 FENDER AS (SPECIAL FOR ROPS)
30E0753 FENDER AS (SPECIAL FOR ROPS, RIPPER)
42E0017 BOTTOM GUARD AS
42E0017 BOTTOM GUARD AS (SPECIAL FOR SHANG CHAI)
42E0019 BOTTOM GUARD AS (SWAMP)
42E0023 FLOOR PLATE AS
46C3857 BATTERY WIRING GP
46C3428 BATTERY WIRING
46C3890 LIGHTING GROUP
46C3425 FRONT WIRING
46C5563 FRAME WIRING
46C3424 ENGINE WIRING
46C3427 CAB WIRING
46C3429 CONSOLE WIRING
46C3857 BATTERY WIRING GP
46C5292 BATTERY WIRING
46C3890 LIGHTING GROUP
46C2406 LIGHTING GROUP
46C2367 REAR LIGHT
46C5560 FRONT WIRING
46C5563 FRAME WIRING
46C5787 ENGINE WIRING
46C3427 CAB WIRING
46C3429 CONSOLE WIRING
1
2
4
4
5
6
7
8
9
10
11
12
13
14
15
Позиция на иллюстрации
Заводской номер детали
Название детали
1
03B0289
Гайка
2
06B0396
Washer
4
05B0072
Болт
5
08C2948
Cable
6
08C2949
Cable
7
37B0004
Хомут
8
37B0108
Аккумулятор
9
08C2952
Cable
10
00B0256
Болт
11
21A1746
Plate
12
34B0087
Выключатель питания
13
08C2951
Cable
14
08C2950
Cable
15
06B0395
Washer
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
