Каталог запасных частей к технике: LiuGong CLG-B160. 32E1543 STRAIGHT TILT BLADE (SWAMP)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
16
17
18
18
18
19
19
19
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
35
35
35
36
37
38
38
39
39
40
41
42
43
44
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 03B1090 | Nut | |
| 2 | 02B0298 | Bolt | |
| 3 | 22D0878 | Cutting tool | |
| 4 | 10A4388 | Adjusting shim | |
| 5 | 10A4389 | Adjusting shim | |
| 6 | 01B0730 | Bolt | |
| 7 | 06B0401 | Washer | |
| 8 | 16D0686 | Support | |
| 9 | 10B0014 | Ниппель | |
| 10 | 53A1077 | Support | |
| 11 | 13A3595 | Lock plate | |
| 12 | 00B0243 | BOLT | |
| 13 | 06B0398 | Washer | |
| 14 | 60A1660 | Pin | |
| 15 | 53A1076 | Support | |
| 16 | 60A1661 | Pin | |
| 17 | 63A0249 | Screw rod | |
| 18 | 03B1167 | Nut | |
| 19 | 00B0565 | Bolt | |
| 20 | 17A3033 | Cutting edge | |
| 21 | 17A3191 | Cutting edge | |
| 22 | 72A1187 | Cutting edge | |
| 23 | 10A4388 | Adjusting shim | |
| 24 | 10A4389 | Adjusting shim | |
| 25 | 01B0280 | BOLT | |
| 26 | 16D0747 | Support | |
| 27 | 21D0522 | Push rod | |
| 28 | 00D4446 | Trunnion | |
| 29 | 71A0745 | Bearing pedestal | |
| 30 | 01B0357 | BOLT | |
| 31 | 71A0707 | Bearing pedestal | |
| 32 | 00D4445 | Trunnion | |
| 33 | 21D0521 | Push rod | |
| 34 | 72A1186 | Cutting edge | |
| 35 | 06B0399 | Washer | |
| 36 | 00B0234 | BOLT | |
| 37 | 00B0596 | Bolt | |
| 38 | 06B0456 | Washer | |
| 39 | 03B1166 | Nut | |
| 40 | 63A0322 | Screw rod | |
| 41 | 03B0294 | Гайка | |
| 42 | 00B0220 | BOLT | |
| 43 | 72A1457 | Bush | |
| 44 | 72A1456 | Bush |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
