Каталог запасных частей к технике: LiuGong CLG-B160. 12C2121 BLADE CONTRAL VAVLE
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
43
44
44
44
45
46
47
48
49
50
51
52
53
54
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 70A0536 | Vavle body | |
| 2 | 55A3300 | Bushing | |
| 3 | 65A0400 | Vavle stem | |
| 4 | 65A0395 | Slide vavle | |
| 5 | 65A0401 | Spool | |
| 6 | 75A0666 | Spring | |
| 7 | 52A0462 | Bracket | |
| 8 | 12B1166 | O-ring | |
| 9 | 66A0269 | Dowel pin | |
| 10 | 11A4546 | Plate | |
| 11 | 00B0239 | Болт | |
| 12 | 06B0008 | Шайба | |
| 13 | 70A0537 | Bearing housing | |
| 14 | 75A0657 | Spring | |
| 15 | 10A4988 | Washer | |
| 16 | 00B0381 | Болт | |
| 17 | 06B0008 | Шайба | |
| 18 | 11A4549 | Plate | |
| 19 | 55A3304 | Bushing | |
| 20 | 01B0836 | Bolt | |
| 21 | 06B0002 | Шайба | |
| 22 | 72A1297 | Vavle | |
| 23 | 75A0667 | Spring | |
| 24 | 52A0643 | Bracket | |
| 25 | 12B1168 | O-ring | |
| 26 | 13A4166 | Plate | |
| 27 | 00B0386 | BOLT | |
| 28 | 06B0008 | Шайба | |
| 29 | 55A3306 | Socket | |
| 30 | 55A3283 | Bearing housing | |
| 31 | 75A0667 | Spring | |
| 32 | 55A3307 | Jacket | |
| 33 | 55A3308 | Bushing | |
| 34 | 01B0837 | Bolt | |
| 35 | 06B0008 | Шайба | |
| 36 | 70A0538 | Housing | |
| 37 | 00B0331 | BOLT | |
| 38 | 06B0002 | Шайба | |
| 39 | 56A1475 | Steel ball | |
| 40 | 65A0402 | Plunger | |
| 41 | 75A0670 | Spring | |
| 42 | 53A1090 | Oil plug | |
| 43 | 12B1170 | O-ring | |
| 44 | 12B1168 | O-ring | |
| 45 | 12B1262 | O-ring | |
| 46 | 13A4168 | Plate | |
| 47 | 12B1322 | O-ring | |
| 48 | 00B0188 | Болт | |
| 49 | 06B0013 | Шайба | |
| 50 | 11A4552 | Plate | |
| 51 | 12A3197 | Plate | |
| 52 | 01B0814 | Bolt | |
| 53 | 06B0008 | Шайба | |
| 54 | 12C2125 | Safety vavle | |
| 55 | 12C2127 | Vavle |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
