48C1878 HOOD (A)
48С1878 HOOD (B)
44E0468 ENGINE HOOD AS (C)
47E0433 002 ATTACHMENT AND OIL SPECIFICATION
1
2
2
2
2
2
2
2
3
3
3
3
3
3
3
4
4
4
4
4
4
5
6
7
8
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
06B0019
Шайба
2
06B0002
Шайба
3
06B0030
WASHER
4
06B0012
Шайба
5
43D0843
Grill
6
84A1219
Rubber plate
7
48C1725
Baffle
8
84A1218
Rubber plate
9
35D0764
Baffle
10
48C0890
Door-rh
11
42 D1082
Bracket
12
48C1734
Bracket
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
