Каталог запасных частей к технике: LiuGong CLG-925D. 12C2410 000 MAIN CONTROL VALVE
103
104
153
153
154
154
154
154
154
154
154
155
158
159
159
162
162
162
163
163
163
163
163
163
163
164
164
164
164
164
164
164
165
165
165
165
165
165
165
165
165
165
165
165
165
165
165
165
165
165
165
165
166
166
166
166
166
166
166
166
166
167
167
167
168
168
168
168
169
169
169
169
201
201
201
201
202
202
202
202
203
203
203
203
204
204
204
204
204
204
206
206
209
252
252
253
261
261
261
261
261
261
262
262
262
262
264
264
264
264
264
264
272
273
273
273
273
301
302
303
304
305
306
307
309
310
324
325
328
329
331
331
331
331
332
332
332
332
332
332
333
333
334
335
335
336
336
336
337
338
339
355
356
371
371
372
373
375
377
378
379
391
392
511
511
515
516
516
517
521
521
521
521
523
523
551
551
551
551
551
551
551
552
552
561
561
561
561
561
561
561
561
561
561
561
561
561
601
602
602
602
602
603
603
605
605
611
611
971
971
974
974
975
976
977
978
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 101 | 78А0362 | Valve body | |
| 102 | 78А0363 | Valve body | |
| 103 | 12С2411 | Valve gp | |
| 104 | 78А0365 | Valve block | |
| 153 | 05А0248 | PLUG | |
| 154 | 05А0250 | PLUG | |
| 155 | 05А0249 | Plug | |
| 158 | 55А1687 | Plug | |
| 159 | 05А0251 | PLUG | |
| 162 | 12В0994 | O-ring | |
| 163 | 12В0995 | O-ring | |
| 164 | 12В0748 | O-ring | |
| 165 | 12В0749 | O-ring | |
| 166 | 12В0750 | O-ring | |
| 167 | 12В0751 | O-ring | |
| 168 | 12В0996 | O-ring | |
| 169 | 12В0752 | O-ring | |
| 201 | 53А0507 | Spring cover | |
| 202 | 53А0508 | Cover cap | |
| 203 | 53А0509 | Spring cover | |
| 204 | 53А0510 | Cover cap | |
| 206 | 53А0593 | Valve cap | |
| 209 | 04А0731 | FLANGE | |
| 252 | 12С1157 | Relief valve | |
| 253 | 53А0663 | Valve cap | |
| 261 | 12В0753 | O-ring | |
| 262 | 12В0754 | O-ring | |
| 264 | 12В0755 | O-ring | |
| 272 | 04В0539 | Hex screw | |
| 273 | 04В0498 | Hex screw | |
| 301 | 65А0213 | Travel spool | |
| 302 | 44С0385 | Arm spool | |
| 303 | 65А0453 | Spool | |
| 304 | 65А0110 | Bucket spool | |
| 305 | 65А0180 | Spool | |
| 306 | 44С0352 | Arm spool gp | |
| 307 | 65А0421 | Spool | |
| 309 | 65А0182 | Spool | |
| 310 | 65А0107 | Золотник хода | |
| 324 | 75А0215 | Spring | |
| 325 | 75А0216 | Spring | |
| 328 | 75А0217 | Spring | |
| 329 | 75А0218 | Spring | |
| 331 | 56А0369 | Spring holder | |
| 332 | 56А0370 | Spring holder | |
| 333 | 00В0418 | Bolt | |
| 334 | 55А1348 | Bushing | |
| 335 | 55А1349 | Bushing | |
| 336 | 00В0419 | Bolt | |
| 337 | 55А1874 | Block | |
| 338 | 55А1351 | Bushing | |
| 339 | 55А1352 | Bushing | |
| 355 | 65А0260 | Piston | |
| 356 | 50А0158 | Поршень | |
| 371 | 75А0219 | Spring | |
| 372 | 75А0220 | Spring | |
| 373 | 75А0351 | Spring | |
| 375 | 75А0352 | Spring | |
| 377 | 75А0272 | Spring | |
| 378 | 75А0273 | Spring | |
| 379 | 10В0174 | Spring | |
| 391 | 44С0325 | Travel valve spool gp | |
| 392 | 65А0277 | Spool | |
| 511 | 65А0187 | POPPET | |
| 515 | 65А0188 | Poppet | |
| 516 | 65А0189 | POPPET | |
| 517 | 65А0216 | Poppet | |
| 521 | 75А0225 | Пружина | |
| 523 | 75А0226 | Пружина | |
| 551 | 05А0352 | PLUG | |
| 552 | 05А0253 | Заглушка | |
| 561 | 12В0756 | Кольцо круглого сечения | |
| 601 | 12С1364 | Ass'y.main | |
| 602 | 12С1334 | Ass'y.port relief | |
| 603 | 12С0763 | Разгрузочный клапан канала | |
| 605 | 12С1357 | Relief valve | |
| 611 | 12С1335 | Ass'y.nega-con relief | |
| 971 | 01В0568 | Hex bolt | |
| 974 | 04В0502 | Hex screw | |
| 975 | 04В0608 | Hex screw | |
| 976 | 04В0540 | Hex screw | |
| 977 | 74А1914 | Nameplate | |
| 978 | 60А0817 | Pin |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
