Каталог запасных частей к технике: LiuGong CLG-922LC. 46C3917(E) CAB WIRING AS

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано Ammann BOMAG CARMIX CASE IH Changlin ChengGong Dimex Doosan DYNAPAC Foton HAMM Hidromek Hitachi Hyundai JCB JLG John Deere Komatsu LIEBHERR LiuGong Lonking (LongGong) Luneng MANITOU Mitsuber New Holland PENGPU RM-Terex SANY SDLG SEM Shantui Shehwa HBXG Soosan TIGARBO VOGELE Volvo WAY WIRTGEN XCMG XGMA Xiamen YTO Yuchai Zoomlion Автокран АЗСМ Алтайлесмаш Амкодор АОМЗ Атек АТЗ Балканкар Рекорд БелАЗ Беловеж Борекс Брянский Арсенал Булат ВЭКС ГАЗ Геомаш Гидромаш Донекс Дормаш Дормашина Дорэлектромаш ДЭЗ ЕлАЗ ЗЗГТ Ижнефтемаш Канаш-электрокар КЗКТ ККЗ Клевер Клинцовский автокрановый завод КМЗ КМЗ 1 Мая Ковровец Коммаш Кранэкс КЭЗ КЭМЗ ЛЗА МАЗ МЗИК МЗКМ МЗКТ Михневский РМЗ МоАЗ Мозырский МЗ МТЗ ОЗП Онежец ПАО "ТЗА" ППС Детва Промтрактор ПТЗ Раскат СпецАгрегат ТВЭКС ТТМ УВЗ Угличмаш УЗТМ ХТЗ ЧЗКМ ЧСДМ ЧТЗ ЭКСКО ЭКСМАШ ЮрМаш

Модель Не выбрано CLG 425 (2010) CLG 777A-S (2010) CLG-2040H (2045H, 2050HL, 2040H, 2045H, 2050HL) (2016) CLG-220 (2008) CLG-225 (2008) CLG-365A (2012) CLG-375 (2008) CLG-375A (2008) CLG-385A (2008) CLG-4165 (2015) CLG-418 (2008) CLG-4215 (2010) CLG-612 (2008) CLG-614 (2010) CLG-618 (2010) CLG-626R CLG-766 (2015) CLG-766A (2012) CLG-816G (2012) CLG-835 CLG-835 (2015) CLG-835H (2015) CLG-836 (2015) CLG-842 CLG-842 CLG-842 (2015) CLG-855N (2015) CLG-856 (2015) CLG-856H (2015) CLG-856I CLG-862 (2015) CLG-877 (2015) CLG-888 (2015) CLG-904С (2007) CLG-915D CLG-915D CLG-920D CLG-920E (2015) CLG-922D CLG-922LC CLG-922LC (2008) CLG-925 (2015) CLG-925D (2015) CLG-933E (2010) CLG-B160 (2010)

Схема > Не выбрано 45E0906 002 DECAL GROUP 45E0906 002 DECAL GROUP 34E0078 003 REVOLVING FRAME AS 34E0078(A) REVOLVING FRAME 34E0078(B) HANDRAIL 00E0537 013 ENGINE SYSTEM 00E0537(A) ENGINE 00E0537(B) SHOCK ABSORBER MOUNTING 00E0537(C) FAN MOUNTING 00E0537(D) COUPLNG MOUNTING 00E0537(E) AIR FILTER MOUNTING 00E0537(F) MUFFLER MOUNTING 00E0537(G) OIL FILTER PIPE 00E0537(H) FUEL TANK AND SUPPORT 00E0537(I) FUEL PIPE 1 00E0537(J) FUEL PIPE 2 00E0537(K) COOLER SYSTEM PIPE 00E0537(L) RESERVE TANK SUPPORT 21C0431 000 FUEL TANK 20C0576 007 RADIATOR GP 40C0999 000 AIR FILTER 15E0493 000 HYDRAULIC SYSTEM 15E0585 000 HYDRAULIC SYSTEM 15E0494 009 MAIN HYDRAULIC SYSTEM 15E0494(A) OIL INPUT PIPING 15E0494(B) OIL OUTPUT PIPING 15E0494(C) MAIN HYDRAULIC PIPING (1) 15E0494(D) MAIN HYDRAULIC PIPING (2) 15E0494(E) MAIN HYDRAULIC PIPING (3) 15E0494(F) MAIN HYDRAULIC PIPING (4) 15E0494(G) MAIN HYDRAULIC PIPING (5) 15E0494(H) MAIN HYDRAULIC PIPING (6) 15E0494(I) MAIN HYDRAULIC PIPING (7) 15E0494(J) SWING PIPINGS 21C0341 000 HYDRAULIC OIL TANK 11C0841 001 PUMP 11C0590 001 PILOT PUMP 11C0591 001 MAIN PUMP AS 12C1366 001 PRESSURE REDUCING VALVE 12C0778 PRESSURE REDUCING VALVE 15C0203 001 ADJUSTER 12C2158 000 MAIN CONTROL VALVE 12C2158 000 MAIN CONTROL VALVE 12C2158 000 MAIN CONTROL VALVE 12C2466 000 MAIN CONTROL VALVE 12C2466 000 MAIN CONTROL VALVE 12C2466 000 MAIN CONTROL VALVE 11C0587 002 SWING MOTOR & REDUCER 11C0587 002 SWING MOTOR & REDUCER 12C0756 000 CHECK VALVE AS 12C2289 000 CHECK VALVE AS 12C1903 000 CHECK VALVE AS 13E0061 002 TRAVEL HYDRAULIC SYSTEM 13E0061(A) TRAVEL HYDRAULIC SYSTEM (A) 13E0061(B) TRAVEL HYDRAULIC SYSTEM (B) 11C0264 003 TRAVEL MOTOR&REDUCTION GEAR 11C0264 003 TRAVEL MOTOR&REDUCTION GEAR 12C0240 001 ROTARY CONNECTION 12E0115 007 PILOT HYDRAULIC SYSTEM 12E0115(A) PILOT HYDRAULIC SYSTEM (A) 12E0115(B) PILOT HYDRAULIC SYSTEM (B) 12E0115(C) PILOT HYDRAULIC SYSTEM (C) 12E0115(D) PILOT HYDRAULIC SYSTEM (D) 12E0115(E) PILOT HYDRAULIC SYSTEM (E) 12E0115(F) PILOT HYDRAULIC SYSTEM (F) 12E0115(G) PILOT HYDRAULIC SYSTEM (G) 12E0115(H) PILOT HYDRAULIC SYSTEM (H) 12E0115(I) PILOT HYDRAULIC SYSTEM (I) 12E0115(J) PILOT HYDRAULIC SYSTEM (J) 12E0115(K) PILOT HYDRAULIC SYSTEM (K) 12C0914 002 PILOT VALVE GP 12C0925 002 HAND PILOT VALVE 12C0926 002 PILOT VALVE AS 11E0486 001 WORK IMPLEMENT LINES AS 11E0486(A) BUCKET CYLINDER LINES AS 11E0486(B) ARM CYLINDER LINES AS 11E0486(C) BOOM CYLINDER LINES AS 11E0486(D) WORK IMPLEMENT LINES AS 10C0248 000 BUCKET CYLINDER AS 10C0826 000 ARM CYLINDER 10C0260 001 BOOM CYLINDER AS-LH 10C0261 001 BOOM CYLINDER AS-RH 12E0116 002 ATTACHMENT PILOT LINES 12C0256 001 FOOT PILOT VALVE 15E0491 006 ATTACHMENT PLATFORM LINES 11E0487 003 ATTACHMENT WORK LINES 11E0487(A) ATTACHMENT WORK LINES 11E0487(B) ATTACHMENT WORK LINES 11E0487(C) ATTACHMENT WORK LINES 12E0133 002 QUICK CONNECTOR CONTROL LINES 12E0133(A) QUICK CONNECTOR CONTROL LINES 12E0133(B) QUICK CONNECTOR CONTROL LINES 22E0967 000 ELECTRICAL SYSTEM 22E1041 000 ELECTRICAL SYSTEM 22E1042 000 ELECTRICAL SYSTEM 46C3917 001 CAB WIRING AS 46C3917(A) CAB WIRING AS 46C3917(B) CAB WIRING AS 46C3917(C) CAB WIRING AS 46C3917(D) CAB WIRING AS 46C3917(E) CAB WIRING AS 46C3314 001 FLOOR PLATE WIRING AS 46C3918 004 FRAME WIRING AS 46C3918(A) FRAME WIRING AS 46C3918(B) FRAME WIRING AS 46C3918(C) FRAME WIRING AS 46C3918(D) FRAME WIRING AS 46C3918(E) FRAME WIRING AS 46C3918(F) FRAME WIRING AS 46C3918(G) FRAME WIRING AS 46C3918(H) FRAME WIRING AS 46C3918(I) FRAME WIRING AS 46C3924 000 CONTROL CASE AS 46C3922 001 ENGINE WIRING AS 46C3922(A) ENGINE WIRING AS 46C3922(B) ENGINE WIRING AS 46C3922(C) ENGINE WIRING AS 46C4252 000 QUICK COUPLER WIRING AS 46C3649 001 ROTATING BEACON WIRING AS 23E0246 005 AIR CONDITIONING SYSTEM 23E0246(A) AIR CONDITIONING SYSTEM 23E0246(B) AIR CONDITIONING SYSTEM 23E0246(C) AIR CONDITIONING SYSTEM 23E0246(D) AIR CONDITIONING SYSTEM 23E0246(E) AIR CONDITIONING SYSTEM 23E0246(F) AIR CONDITIONING SYSTEM 46C3629 001 CONDENSER 46C3351 002 COMPRESSOR BRACKET AS 32E0783 000 WORK IMPLEMENT SYSTEM 32E0783(A) BOOM ASS`Y 32E0783(B) ARM ASS`Y 32E0783(C) LINKAGE 32E0866 000 IMPLEMENT SYSTEM 32E0866(A) BOOM ASS`Y 32E0866(B) ARM ASS`Y 32E0866(C) LINKAGE ASS`Y 43C0270 002 LINK 00C0392 000 GREASE LINES 43C1707 000 BUCKET AS 43C0343 001 BUCKET 43C0855 000 BUCKET AS 33E0082 001 UNDERCARRIAGE SYSTEM 33E0082(A) TRACK FRAME 33E0082(B) SWING BEARING 33E0082(C) LOWER ROLLER 33E0082(D) TENSION DEVICE 33E0082(E) SPROCKET 33E0091 001 UNDERCARRIAGE SYSTEM 33E0091(A) TRACK FRAME 33E0091(B) SWING BEARING 33E0091(C) LOWER ROLLER 33E0091(D) TENSION DEVICE 33E0091(E) SPROCKET 25C0063 000 TRACK AS 44C0640 001 TENSIONER 41E0376 001 CAB AS 47C1052 001 CAB (WITH DECORATION) 47C1153 000 CABIN ASSY 47C1153(A) CABIN ASSY 47C1153(B) CABIN ASSY 47C1153(C) CABIN ASSY 47C1153(D) CABIN ASSY 47C1153(E) CABIN ASSY 47C1154 001 DECORATION AS 47C1075 002 FLOOR PLATE AS 47C1074 001 SEAT AS 34C1389 001 CONSOLE AS-RH 34C1388 001 CONSOLE AS-LH 47C1048 001 SEAT 44E0299 012 ENGINE HOOD AS 44E0299(A) ENGINE HOOD AS 44E0299(B) ENGINE HOOD AS 44E0299(C) ENGINE HOOD AS 44E0299(D) ENGINE HOOD AS 44E0299(E) ENGINE HOOD AS 44E0299(F) ENGINE HOOD AS 44E0299(G) ENGINE HOOD AS 44E0299(H) COUNTERWEIGHT SUPPORT 27C0312 001 TOOL KIT 48C0848 002 ENGINE HOOD 48C0854 001 DOOR-LH 48C1209 000 DOOR-LH 48C0853 001 DOOR-LH 48C0855 000 DOOR-RH 47E0432 002 ATTACHMENT AND OIL SPECIFICATION

1

2

3

4

5

6

7

Позиция на иллюстрации	Заводской номер детали		Название детали
1	08C2905		CAB HARNESS
2	08C2900		HARNESS
3	20A6655		Insert
4	00B0085		Болт
5	06B0006		Шайба
6	06B0005		WASHER
7	37B0119		Соединения блокировочного кабеля

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
