Каталог запасных частей к технике: LiuGong CLG-920E. 47C1349 000 DECORATION AS
1
2
3
4
5
5
6
7
8
8
8
8
8
8
8
9
10
10
10
11
11
11
12
13
14
15
16
17
18
19
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
27
28
29
30
31
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 86A1359 | Air duct | |
| 2 | 86A1357 | Air duct | |
| 3 | 86A1356 | Air duct | |
| 4 | 86A1181 | Cover | |
| 5 | 27A1867 | Plate | |
| 6 | 47C1840 | HORN COVER | |
| 7 | 04B0210 | SCREW | |
| 8 | 04B0056 | Винт | |
| 9 | 03B0036 | NUT | |
| 10 | 46C4556 | VENT | |
| 11 | 04B0173 | SCREW | |
| 12 | 86A1182 | Cover | |
| 13 | 86A1002 | HANDLE | |
| 14 | 86A1189 | Storage box | |
| 15 | 86A1185 | Cover | |
| 16 | 86A1351 | Air duct | |
| 17 | 85A3094 | Sponge | |
| 18 | 85A2779 | Sponge | |
| 19 | 23D1891 | Cover | |
| 20 | 83A1379 | Grommet | |
| 21 | 06B0005 | WASHER | |
| 22 | 06B0219 | Шайба | |
| 23 | 00B0075 | BOLT | |
| 24 | 00B0001 | Шайба | |
| 25 | 00B0002 | Болт | |
| 26 | 00B0012 | BOLT | |
| 27 | 47C1890 | Fastener | |
| 28 | 86A1363 | Plate | |
| 29 | 19A0552 | PLATE | |
| 30 | 46C4557 | VENT | |
| 31 | 47C1883 | VENT | |
| 32 | 86A1013 | COVER | |
| 33 | 86A1355 | Air duct | |
| 34 | 86A1353 | AIR DUCT | |
| 35 | 86A1352 | AIR DUCT | |
| 36 | 86A1354 | Air duct | |
| 37 | 86A1531 | MOUNTING SUPPORT | |
| 38 | 83A1447 | BOOT | |
| 39 | 86A1208 | CUP HOLDER | |
| 40 | 86A1186 | Cover | |
| 41 | 23D2525 | Cover | |
| 42 | 86A1205 | CONNECTOR | |
| 43 | 86A1010 | Housing | |
| 44 | 04B0204 | SCREW | |
| 45 | 06B0133 | Шайба | |
| 46 | 34C1984 | LOCK BLOCK | |
| 47 | 04B0752 | SCREW | |
| 48 | 10A6368 | LOCK PLATE | |
| 49 | 86A1011 | Tank cover | |
| 50 | 86A1184 | Cover | |
| 51 | 86A1183 | Cover | |
| 52 | 47C1539 | Vent | |
| 53 | 86A1360 | Air duct | |
| 54 | 86A1632 | Air duct | |
| 55 | 86A1358 | Air duct | |
| 56 | 86A1187 | Cover | |
| 57 | 86A1188 | Cover | |
| 58 | 47C1882 | Lock |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
