Каталог запасных частей к технике: LiuGong CLG-915D. 12C1735 001 MAIN CONTROL VALVE
101
102
155
155
156
156
156
156
156
156
156
156
164
166
166
166
201
201
201
201
201
201
201
201
204
204
204
204
206
206
206
206
206
206
206
206
262
262
262
262
262
262
262
262
262
262
262
262
265
265
265
265
265
265
265
265
273
273
273
273
301
302
303
304
305
306
306
307
308
309
309
310
321
321
322
323
324
325
326
326
327
329
332
332
332
332
332
332
332
332
332
332
333
333
333
333
333
337
337
337
337
338
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 101 | 78A0316 | VALVE BODY | |
| 102 | 78A0317 | VALVE BODY | |
| 154 | 05A0248 | Заглушка | |
| 154 | 05A0589 | PLUG | |
| 155 | 05A0249 | Заглушка | |
| 155 | 05A0592 | Plug | |
| 156 | 05A0250 | Заглушка | |
| 156 | 05A0590 | Plug | |
| 157 | 05A0638 | PLUG | |
| 158 | 03B0897 | Plug | |
| 158 | 05A0396 | Plug | |
| 161 | 12B0711 | O-RING | |
| 162 | 12B0551 | O-RING | |
| 163 | 12B1337 | O-RING | |
| 164 | 12B1338 | O-RING | |
| 166 | 12B0528 | O-RING | |
| 167 | 12B0527 | O-RING | |
| 168 | 12B0708 | O-RING | |
| 169 | 12B1339 | O-RING | |
| 170 | 12B0902 | O-RING | |
| 201 | 53A0697 | VALVE CAP | |
| 204 | 53A0699 | VALVE CAP | |
| 206 | 53A0590 | VALVE CAP | |
| 211 | 12C1349 | SUB-ASS'Y.LOCK VAVLE SELECTOR | |
| 214 | 78A0235 | COVER | |
| 215 | 78A0318 | VALVE BODY | |
| 218 | 12C1352 | ASS'Y.CONTROL VAVLE FOR OPTION | |
| 219 | 16C0048 | PLUG AS | |
| 221 | 05A0630 | PLUG | |
| 221 | 05A0639 | PLUG | |
| 262 | 12B0911 | O-ring | |
| 265 | 12B1340 | O-RING | |
| 271 | 05A0640 | PLUG | |
| 272 | 05A0641 | PLUG | |
| 273 | 05A0642 | PLUG | |
| 301 | 15C0197 | ASS'Y.BOOM SPOOL | |
| 302 | 15C0198 | ASS'Y.ARM SPOOL | |
| 303 | 15C0246 | SPOOL | |
| 304 | 65A0265 | BUCKET SPOOL | |
| 305 | 65A0267 | BOOM SPOOL | |
| 306 | 65A0268 | TRAVEL SPOOL | |
| 307 | 15C0247 | SPOOL | |
| 308 | 15C0199 | ASS'Y.ARM CONFLUENCE SPOOL | |
| 309 | 65A0271 | SPOOL | |
| 310 | 65A0272 | SPOOL | |
| 311 | 15C0248 | SPOOL | |
| 321 | 75A0360 | SPRING | |
| 322 | 75A0361 | SPRING | |
| 323 | 75A0362 | SPRING | |
| 324 | 75A0363 | SPRING | |
| 325 | 75A0364 | SPRING | |
| 326 | 75A0365 | SPRING | |
| 327 | 75A0366 | SPRING | |
| 329 | 75A0367 | SPRING | |
| 332 | 56A0457 | Bracket | |
| 333 | 04B0564 | Scrwe | |
| 337 | 39A0365 | BUSHING | |
| 338 | 39A0366 | BUSHING | |
| 512 | 65A0273 | POPPET | |
| 513 | 65A0274 | Poppet | |
| 514 | 65A0275 | POPPET | |
| 522 | 75A0369 | SPRING | |
| 524 | 75A0370 | SPRING | |
| 552 | 05A0475 | PLUG | |
| 553 | 03B0723 | Plug | |
| 556 | 05A0476 | Plug | |
| 558 | 04B0625 | ADJUSTING SCREW | |
| 559 | 03B1130 | LOCKNUT | |
| 562 | 12B0901 | O-RING | |
| 601 | 12C1353 | ASS'Y.MAIN RELIEF | |
| 602 | 12C1334 | ASS'Y.PORT RELIEF | |
| 603 | 12C1354 | ASS'Y.PORT RELIEF | |
| 611 | 12C1335 | ASS'Y.NEGA-CON RELIEF | |
| 973 | 05A0644 | HEX PLUG | |
| 974 | 05A0645 | HEX PLUG | |
| 977 | 74A1914 | Nameplate | |
| 978 | 55A2759 | PIN |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
