Каталог запасных частей к технике: LiuGong CLG-816G. 11E0371 009 HYDRAULIC SYSTEM

Тип техники

Марка

Модель

Схема

1

2

2

3

3

3

3

4

5

6

8

9

10

10

10

11

12

13

13

13

14

15

16

17

18

19

20

21

21

22

23

24

25

26

27

28

29

29

29

30

31

33

34

35

36

37

38

38

39

40

41

42

43

44

45

46

47

48

49

50

Позиция на иллюстрации	Заводской номер детали		Название детали
1	10C0753		BUCKET TILTING CYLINDER
2	06C3769		HOSE AS
3	06C4079		HOSE AS
4	19A0425		CLAMP
5	00B0005		BOLT
6	06B0347		WASHER
8	83H0011		SHIM
9	03B0053		NUT
10	06C3244		HOSE AS
11	09C1160		CLAMP
12	09C0708		CLAMP
13	06C2398		HOSE AS
14	00C0838		PILOT CONTROL LINES
15	12C1255		PRIORITY VALVE AS
16	30A0317		SUCTION HOSE
17	15B0005		Хомут
18	06C3716		HOSE AS
19	11C1434		PUMP AS
20	06C3245		HOSE AS
21	12B0224		Кольцо круглого сечения
22	12C1253		RETURN VALVE AS
23	05C1546		HOSE AS
24	00B0038		Болт
25	06B0009		Шайба
26	06B0350		WASHER
27	21C0244		HYDRAULIC OIL TANK
28	06C2396		HOSE AS
29	06C2394		HOSE AS
30	12C1327		CONTROL VALVE AS
31	00C0854		TUBE AS
33	10C0646		BOOM CYLINDER AS-LH
34	10D2785		TUBE AS
35	10C0647		BOOM CYLINDER AS-RH
36	10D2784		TUBE AS
37	00B0026		Болт
38	06B0348		WASHER
39	05A0287		PLUG
40	03B0649		NUT
41	14A1750		NUT BLOCK
42	82A0765		GASKET
43	12C1786		CONTROL VALVE AS
44	10A4599		CLAMP
45	00B0075		BOLT
46	84A1866		Plug
47	00B0035		Болт
48	06B0007		WASHER
49	06B0349		WASHER
50	06C9619		HOSE AS

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
