Каталог запасных частей к технике: LiuGong CLG-766A. 00E0719 003 ENGINE SYSTEM
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
21
22
22
22
22
22
22
22
22
22
23
24
25
26
27
28
29
30
31
31
31
32
32
33
34
35
36
37
38
39
39
40
41
41
41
42
42
42
43
44
45
45
46
46
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
60
61
62
63
64
65
66
67
68
69
70
71
72
73
81
82
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 20C1014 | COOLING SYSTEM | |
| 2 | 15B0055 | Хомут | |
| 3 | 83A1323 | HOSE | |
| 4 | 15B0017 | Хомут | |
| 5 | 29A0562 | Bracket | |
| 6 | 12A4416 | Plate | |
| 7 | 83A1150 | Intake pipe | |
| 8 | 30A0613 | Fuel hose | |
| 9 | 30A0612 | Fuel hose | |
| 10 | 15B0067 | CLAMP | |
| 11 | 15D0775 | Connector | |
| 12 | 23C0275 | Throttle control system | |
| 13 | 40C1367 | MUFFLER | |
| 14 | 05D0352 | EXHAUST PIPE | |
| 15 | 40C2524 | CAP | |
| 16 | 09C0095 | T-CLAMP | |
| 17 | 15B0037 | Clamp | |
| 18 | 83A1148 | INTAKE PIPE | |
| 19 | 40C1930 | AIR PRE-FILTER | |
| 20 | 55A2669 | Sleeve | |
| 21 | 00B0331 | BOLT | |
| 22 | 06B0347 | WASHER | |
| 23 | 40C1528 | PLATE | |
| 24 | 10A4338 | Plate | |
| 25 | 01B0215 | BOLT | |
| 26 | 11A0941 | Шайба | |
| 27 | 17B0117 | Соединение в сборе | |
| 28 | 06B0360 | Washer | |
| 29 | 00B0220 | BOLT | |
| 30 | 00B0341 | BOLT | |
| 31 | 06B0001 | WASHER | |
| 32 | 56A0547 | Gasket | |
| 33 | 40C1259 | CORRUGATED PIPE | |
| 34 | 02D1970 | SUPPORT | |
| 35 | 00B0244 | BOLT | |
| 36 | 06B0351 | WASHER | |
| 37 | 02D4121 | BRACKET | |
| 38 | 04B0002 | Винт | |
| 39 | 57A0006 | Шайба | |
| 40 | 00B0013 | Болт | |
| 41 | 06B0007 | WASHER | |
| 42 | 06B0349 | WASHER | |
| 43 | 21C0470 | FUEL TANK | |
| 44 | 05C3797 | FUEL HOSE | |
| 45 | 00B0019 | Болт | |
| 46 | 06B0030 | WASHER | |
| 47 | 09K0002 | Хомут | |
| 48 | 00B0301 | Болт | |
| 49 | 22A1736 | Plate | |
| 50 | 00A3395 | Connector | |
| 51 | 06B0117 | Шайба | |
| 52 | 00B0005 | BOLT | |
| 53 | 40C0836 | Diesel engine | |
| 54 | 00A5141 | CONNECTOR | |
| 55 | 05C3899 | HOSE AS | |
| 56 | 34C0090 | Шайба | |
| 57 | 00A5143 | CONNECTOR | |
| 58 | 40C1365 | PUMP BODY | |
| 59 | 85A2729 | SEAL PLATE | |
| 60 | 00B0238 | Болт | |
| 61 | 30A0504 | WATER PIPE | |
| 62 | 15B0004 | Хомут | |
| 63 | 00B0002 | Болт | |
| 64 | 15V0110 | T-clamp | |
| 65 | 15B0095 | Хомут | |
| 66 | 20A8661 | Double clamp | |
| 67 | 00B0007 | Болт | |
| 68 | 06B0005 | WASHER | |
| 69 | 06B0348 | WASHER | |
| 70 | 00D3548 | BRACKET | |
| 71 | 02D2565 | BRACKET | |
| 72 | 40C2442 | AIR FILTER | |
| 73 | 40C1213 | ENGINE FAN | |
| 74 | 85A1443 | Fan belt | |
| 75 | 40C1240 | Main filter element | |
| 76 | 40C1241 | Safety filter element | |
| 77 | 53C0324 | Engine oil filter | |
| 78 | 53C0325 | Fuel filter | |
| 79 | 40C1277 | Oil-water separator | |
| 80 | 40C1278 | Start motor | |
| 81 | 03A0814 | SCREW | |
| 82 | 40C2459 | Dipstick |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
