Каталог запасных частей к технике: LiuGong CLG-626R. 23Y0008 Rear Axle Assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
21
21
22
23
24
25
26
27
28
28
29
30
31
32
33
34
34
35
36
38
39
40
41
42
43
44
45
46
47
48
49
50
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 16V0019 | Wheel | |
| 2 | 32W0015 | Rim | |
| 3 | 02V0089 | Bolt | |
| 4 | 03V0538 | Nut | |
| 5 | 71U0023 | Wheel Support | |
| 6 | 00В0056 | Болт | |
| 7 | 06В0002 | Шайба стопорная | |
| 8 | 20U0147 | Cover Plate | |
| 9 | 03V0540 | Nut | |
| 10 | 03V0541 | Nut | |
| 11 | 56U0033 | Washer | |
| 12 | 09V0041 | Fitting key | |
| 13 | 63U0004 | Alxe | |
| 14 | 00В0014 | Болт | |
| 15 | 88А0697 | Lock Washer | |
| 16 | 45W0005 | Detent | |
| 17 | 45W0004 | Brake Asm. | |
| 18 | 03V0542 | Nut | |
| 19 | 06V0250 | Washer | |
| 20 | 00V0352 | Bolt | |
| 21 | 06В0008 | Шайба | |
| 22 | 08V0133 | Pin | |
| 23 | 55U0033 | Shaft Sleeve | |
| 24 | 13V0211 | Seal | |
| 25 | 22V0016 | Bear | |
| 26 | 55U0034 | Shaft Sleeve | |
| 27 | 26V0008 | Bear | |
| 28 | 53U0047 | Bear Cover | |
| 29 | 81U0017 | Washer | |
| 30 | 71U0024 | Bear support | |
| 31 | 15U0087 | Plate | |
| 32 | 00V0185 | Bolt | |
| 33 | 06В0052 | Шайба | |
| 34 | 00В0364 | Bolt | |
| 35 | 45X0014 | Chain guard | |
| 36 | 00В0017 | Болт | |
| 37 | 06В0007 | Шайба | |
| 38 | 41U0011 | Chain wheel | |
| 39 | 00V0353 | Bolt | |
| 40 | 10U0148 | Washer | |
| 41 | 71U0025 | Shaft Joint Support | |
| 42 | 71U0026 | Shaft Joint | |
| 43 | 00V0354 | Bolt | |
| 44 | 06В0019 | Шайба | |
| 45 | 63U0005 | Axle | |
| 46 | 09V0042 | Fitting key | |
| 47 | 09V0043 | Fitting key | |
| 48 | 10В0051 | Grease fitting | |
| 49 | 06V0251 | Washer | |
| 50 | 08V0135 | PIN | |
| 51 | 12U0089 | Shim |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
